Technical Data & Lubricators Filters, Regulators,
SErIES PolyCArBoNATE METAl Bowl / METAl Bowl
SErIES
1000 1500 2000 3000 Bowl w/ SIGhT GlASS
0 – 140 0 – 140 0 – 140 –
Spring range options (psi) Max Inlet Pressure (psi)
– – – 0 – 200
Filter element 5 micron 1000 150 250
PolyCArBoNATE Bowl 1500 150 250
0.5 1.3 1.9 – 2000 150 250
METAl Bowl
Filter bowl cap – manual drain (oz) 3000 – 250
0.4 – – –
METAl / METAl Bowl w/ SIGhT GlASS Temperature range (ºF)
– 1.3 2.4 5.3 1000 23 – 125 23 – 175
PolyCArBoNATE Bowl 1500 23 – 125 23 – 175
0.7 1.0 2.3 – 2000 23 – 125 23 – 175
METAl Bowl
Filter bowl cap – auto drain (oz) 3000 – 23 – 175
0.7 – – –
METAl / METAl Bowl w/ SIGhT GlASS
– 1.0 2.8 5.9
PolyCArBoNATE Bowl
0.6 1.9 4.3 –
METAl Bowl
lubricator bowl capacity
0.7 – – –
METAl / METAl Bowl w/ SIGhT GlASS
– 1.5 3.7 3.2
2000 Series 3000 Series

Components Components
Filter-regulator lubricator Model Filter-regulator lubricator Model
NPT cfm* NPT cfm*
MANUAl DrAIN • METAl BowlS w/ SIGhT GlASS • rElIEVING • MANUAl DrAIN • METAl BowlS w/ SIGhT GlASS • rElIEVING •
w/ GAUGE w/ GAUGE
3/8" P39334-610 L36331-110 96 C38331-610 3/4" P39454-610 L36451-110 201 C38451-610
1/2" P39344-610 L36341-110 120 C38341-610 1" P39464-610 L36461-110 208 C38461-610
3/4" P39354-610 L36351-110 142 C38351-610 AUTo DrAIN • METAl BowlS w/ SIGhT GlASS • rElIEVING •
w/ GAUGE
MANUAl DrAIN • PolyCArBoNATE BowlS w/ GUArD •
rElIEVING • w/ GAUGE 3/4" P39454-614 L36451-110 201 C38451-611
3/8" P39334-600 L36331-100 96 C38331-600 1" P39464-614 L36461-110 208 C38461-611
1/2" P39344-600 L36341-100 120 C38341-600
3/4" P39354-600 L36351-100 142 C38351-600
AUTo DrAIN • METAl BowlS w/ SIGhT GlASS • rElIEVING •
w/ GAUGE
3/8" P39334-614 L36331-110 96 C38331-611
1/2" P39344-614 L36341-110 120 C38341-611
3/4" P39354-614 L36351-110 142 C38351-611
AUTo DrAIN • PolyCArBoNATE BowlS w/ GUArD • rElIEVING •
w/ GAUGE
3/8" P39334-604 L36331-100 96 C38331-601
1/2" P39344-604 L36341-100 120 C38341-601
3/4" P39354-604 L36351-100 142 C38351-601

For further model options, port sizes, and
information regarding flow charts, unit dimensions, ingersollrandproducts.com/accessories
replacement parts, and more, go to:
