11
Technical Data & Lubricators Filters, Regulators,
SErIES PolyCArBoNATE METAl Bowl / METAl Bowl
SErIES
1000 1500 2000 3000 Bowl w/ SIGhT GlASS
lubricator body Aluminum • • • • Max Inlet Pressure (psi)
lubricator sight dome Nylon • • • • 1000 150 250
lubricator inlet tube Urethane • • • • 1500 150 250
Seals Nitrile • • • • 2000 150 250
3000 – 250
Temperature range (ºF)
1000 23 – 125 23 – 175
1500 23 – 125 23 – 175
2000 23 – 125 23 – 175
3000 – 23 – 175
2000 Series 3000 Series
Adjustment Bowl Fill Adjustment Bowl Fill
option Cap option Model option Cap option Model
NPT oz cfm* NPT oz cfm*
METAl BowlS METAl BowlS
3/8" Standard 3.7 Standard 85 L36331-120 3/4" Standard 3.7 Standard 368 L36451-120
1/2" Standard 3.7 Standard 156 L36341-120 1" Standard 3.7 Standard 328 L36461-120
3/4" Standard 3.7 Standard 222 L36351-120 METAl BowlS w/ SIGhT GlASS
METAl BowlS w/ SIGhT GlASS 3/4" Standard 3.7 Standard 368 L36451-110
3/8" Standard 3.7 Standard 85 L36331-110 1" Standard 3.7 Standard 328 L36461-110
1/2" Standard 3.7 Standard 156 L36341-110
3/4" Standard 3.7 Standard 222 L36351-110
PolyCArBoNATE BowlS w/ GUArD
3/8" Standard 4.3 Standard 85 L36331-100
1/2" Standard 4.3 Standard 156 L36341-100
3/4" Standard 4.3 Standard 222 L36351-100
For further model options, port sizes, and
information regarding flow charts, unit dimensions, ingersollrandproducts.com/accessories
replacement parts, and more, go to:
