6 Air Line Accessories | FRLs | Filters

Filters, Regulators, & Lubricators Filters

1000, 1500, 2000, & 3000 Series

1/8 " • 1/4 " • 3/8" • 1/2" • 3/4" • 1" Ports
ARO-Flo compressed air ilters are designed to remove
airborne solid and liquid contaminants. Filters can be
ordered with different elements, including coalescing
models which are capable of removing oil aerosols and
particles down to 0.3 micron. Standard ilters are sold
with 5-micron elements; 40-micron elements can be
purchased and installed separately.

1000 Series 1500 Series

Filter Bowl Filter Filter Bowl Filter
Type Cap Element Model Type Cap Element Model
NPT oz microns cfm* NPT oz microns cfm*
MANUAL DRAIN • METAL BOWLS MANUAL DRAIN • POLYCARBONATE BOWLS W/ GUARD
1/8" Coalescing 0.3 0.3 38 F35111-320 1/4" Coalescing 1.2 0.3 73 F35221-300
1/8" Standard 0.4 5 38 F35111-420 1/4" Standard 1.3 5 73 F35221-400
1/4" Coalescing 0.3 0.3 49 F35121-320 3/8" Coalescing 1.2 0.3 107 F35231-300
1/4" Standard 0.4 5 49 F35121-420 3/8" Standard 1.3 5 107 F35231-400
MANUAL DRAIN • POLYCARBONATE BOWLS W/ GUARD MANUAL DRAIN • METAL BOWLS
1/8" Coalescing 0.3 0.3 38 F35111-300 1/4" Coalescing 1.2 0.3 73 F35221-320
1/8" Standard 0.5 5 38 F35111-400 1/4" Standard 1.3 5 73 F35221-420
1/4" Coalescing 0.3 0.3 49 F35121-300 3/8" Coalescing 1.2 0.3 107 F35231-320
1/4" Standard 0.5 5 49 F35121-400 3/8" Standard 1.3 5 107 F35231-420
AUTO DRAIN • METAL BOWLS MANUAL DRAIN • METAL BOWLS W/ SIGHT GLASS
1/8" Coalescing 0.5 0.3 38 F35111-321 1/4" Coalescing 1.2 0.3 73 F35221-310
1/8" Standard 0.7 5 38 F35111-421 1/4" Standard 1.3 5 73 F35221-410
1/4" Coalescing 0.5 0.3 49 F35121-321 3/8" Coalescing 1.2 0.3 107 F35231-310
1/4" Standard 0.7 5 49 F35121-421 3/8" Standard 1.3 5 107 F35231-410
AUTO DRAIN • POLYCARBONATE BOWLS W/ GUARD AUTO DRAIN • POLYCARBONATE BOWLS W/ GUARD
1/8" Coalescing 0.5 0.3 38 F35111-301 1/4" Coalescing 1.0 0.3 73 F35221-301
1/8" Standard 0.7 5 38 F35111-401 1/4" Standard 1.0 5 73 F35221-401
1/4" Coalescing 0.5 0.3 49 F35121-301 3/8" Coalescing 1.0 0.3 107 F35231-301
1/4" Standard 0.7 5 49 F35121-401 3/8" Standard 1.0 5 107 F35231-401
AUTO DRAIN • METAL BOWLS W/ SIGHT GLASS
1/4" Coalescing 1.0 0.3 73 F35221-311
1/4" Standard 1.0 5 73 F35221-411
3/8" Coalescing 1.0 0.3 107 F35231-311
3/8" Standard 1.0 5 107 F35231-411

*Inlet pressure 90 psi (6.2 bar) with 10 psi drop (0.7 bar)
