Crimp System Pliers

► Only one tool for almost 1000 crimping applications:
usable with all crimping dies and locators 97 49 XX
► Almost parallel crimping motion

> Consistently high crimping quality due to precision dies and ratchet
mechanism (unlockable)
> Crimping pressure has been set precisely (calibrated) in the factory,
re-adjustable
> Optimum transmission of force due to lever action for fatigue-reduced
operation
> Ergonomically designed handles
> Different locators for precise positioning of the connectors
> Crimping dies for applications not covered in the range offered here, 97 43 200 /
may be available on request 97 43 200 A
> Tool body: high-grade chrome vanadium electric steel, oil-hardened
> Approved crimping according to UL in conjunction with KNIPEX wire
ferrules 97 99 330 – 399
> The crimping die can be easily exchanged using two screws.
Please refer to the instruction manual
> Special quality chrome vanadium electric steel, oil-hardened

97 43 05
> With attached crimping dies for non-insulated open plug-type
connectors (4.8 and 6.3 mm connector width)
97 43 06
> With attached crimping dies for insulated terminals and plug 97 43 05
connectors
97 43 66
> With attached crimping dies for MC4 photovoltaic cable connectors
(2.5 / 4 / 6 mm²)
97 43 200
> Foam insert with recesses for crimping dies and locators;
with service tool (Allen key), screws and nuts
97 43 200 A
> Pliers without crimping dies, without casew
97 43 66

With the possibility of crimping
almost all currently available
crimping connections with just
one tool and state-of-the-art
crimping pliers technology, the
crimp system pliers solves almost
all tasks in mobile and stationary
crimping technology and is an
excellent tool for professionals to
use for standard crimping.

97 43 200 with crimping dies 97 49 06 for 97 43 200 with crimping dies 97 49 09 97 43 400 with crimping dies 97 49 24 and
insulated terminals, plug connectors and butt for wire ferrules locator 97 49 93 for D-Sub plugs
connectors

EAN Capacity
Article No. 4003773- mm Pliers Handles Application mm² AWG g
non-insulated open plug-type connectors
97 43 05 031031 200 burnished with multi-component grips 0.5 – 6 20 – 10 618
(4.8 and 6.3 mm connector width)
97 43 06 031048 200 burnished with multi-component grips insulated terminals and plug connectors 0.5 – 6 20 – 10 610

97 43 66 087779 200 burnished with multi-component grips MC4 2.5 – 6 14 – 10 618
97 43 200 030812 200 burnished with multi-component grips 988
97 43 200 A 071587 200 burnished with multi-component grips 574
