Page 373 - HAZET哈蔡特2024英文样本

Pneumatic tools ∙ Cordless tools

Tyre inflators and measuring instruments

Tyre inflators and measuring instruments

9041 Tyre inflator 9041 Tyre inflator ∙ digital

• Special rubber housing protects manometer against light impacts C C C
• Measuring tolerance ± 0.3 bar
• Handle with operating lever and discharge knob (for one-hand use)
• Flexible hose (length 400 mm) with plug-in nipple
• Max. pressure: 12 bar
• Handle with integrated suspension hook
• Manometer measuring range: 0 – 12 bar
Graduation: 0.1 bar
• Manometer diameter: 63 mm
• Scale value in bar
• Air connection inlet: inside
1
thread 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Temperature range: -10°C – 40°C

1 5 4
9041 D-1 385 212378

9041 Tyre inflator ∙ calibrated
• Calibrated device with optimally readable, large manometer C
• Application: Precise filling of tyres and checking the air pressure
• Measuring tolerance 0–4 bar ± 0.08 bar
Measuring tolerance 4–12 bar ± 0.16 bar
• Special rubber housing protects manometer against light impacts
• Handle with operating lever for filling and deflating (for one-hand use)
1 5 4 • Hose with plug-in nipple
9041-1 411 147076 • Handle with integrated suspension hook
• Manometer measuring range: 0 – 12 bar, graduation: 0.1 bar
• Flexible tube, length: 1000 mm
• Manometer diameter: 80 mm
9041 Tyre inflator ∙ digital • Device dimensions: 220 x 150 x 90 mm
• Max. pressure: 12 bar
• Easy and optimal readability also in poor light conditions C • Air connection inlet: inside thread 12.91 mm ( ⁄4″)
1
• Coupler plug: integrated, nominal size 7.2
• Application: Filling tyres and checking the air pressure • Temperature range: -20°C – 60°C
• Special rubber housing protects manometer against light impacts
• Handle with operating lever for filling as well as deflating button for one-hand use
• Hose with plug-in nipple
• Handle with integrated suspension hook
• Manometer measuring range: 0 – 12 bar, graduation: 0.01 bar
• Measuring tolerance: ±1%
• Blue lighting of the display
• Flexible tube, length: 400 mm
• Manometer diameter: 63 mm
• Device dimensions: 262 x 105 x 40 mm
• Display toggles between bar / PSI / kg/cm 2
• Max. pressure: 12 bar
• Power supply: 2 x 1.5V lithium batteries type AAA
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
1
• Coupler plug: integrated, nominal size 7.2
• Temperature range: -20°C – 50°C

1 5 4
B 9041 G-1 585 212385

Components and spare parts from page 500 to 509 Errors excepted 371
