Page 369 - HAZET哈蔡特2024英文样本

Pneumatic tools ∙ Cordless tools

Blind rivet guns

Blind rivet guns

9037 Blind rivet gun 9037 Blind rivet gun

• Pneumatic / hydraulic A/ • Pneumatic / hydraulic A/
Suitable for stainless steel rivets up to 6.4 mm For blind rivets up to 4.8 mm
• Professional riveting, suitable for continuous operation with rivets of • Possible rivet sizes:
up to 6.4 mm made of steel, stainless steel, aluminium and copper Aluminium rivets: 2.4 – 4.8 mm
• Possible rivet sizes: 3.0 ∙ 3.2 ∙ 4.0 ∙ 4.8 ∙ 5.0 ∙ 6.0 and 6.4 mm Steel rivets: 2.4 – 4.8 mm
• 5 nose pieces (one pre-installed) Stainless steel rivets: 2.4 – 3.2 mm
• Thread size of nose pieces: M10 x 1.25 • 4 nose pieces (one pre-installed): 2.4 ∙ 3.2 ∙ 4 ∙ 4.8 mm
• Total stroke: 15.8 mm • Total stroke 14 mm
• High tractive power: 14700 N • With sturdy metal housing
• Particularly low noise level • Tractive power: 8700 N
• Rotary joint for flexible use • Coupler plug with rotary joint for flexible operation
• Rivet and nose piece template on • Air requirement: 1 l/stroke 1
the underside of the rivet gun • Air connection inlet: inside thread 12.91 mm ( ⁄4″)
• Storage of the different nose pieces • Coupler plug: Nominal size 7.2 (included)
on the underside of the rivet gun • Working pressure (bar): 6.3
• Easy oil top ups using special
design of the rivet gun
• Includes maintenance set for oil control
(oil-supported pressure build-up)
• Air requirement: 2.64 l/stroke
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Cold insulated handle

1 5 4 1 N 5 4
db (A) LpA
9037 N-2 2110 205578 9037 SPC 73 1500 150168

Components and spare parts from page 500 to 509 Errors excepted 367
