Pneumatic tools ∙ Cordless tools Pneumatic tools ∙ Cordless tools

Drilling and grinding machines Drilling and grinding machines

9035 Engraving pen 9034 P Sabre saw

• Also for working in areas with restricted access C A/
• Application: Precise and lasting marking (theft protection, installation date,
etc.) on workpieces (up to HRC55) ∙ metals ∙ stone ∙ ceramics ∙ plastics
• Sturdy metal housing
• Noise-dampened
• Slim design and optimised haptics
• Anti-kink spring prevents the hose from kinking
• Knurled power control
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Sound power level: 90 db(A) Lp W
• Vibration acceleration: 2.50 m/s 2
• Hose length: 1.5 m
YouTube Clip

9034 P-018/5
9034-024/5
9034 P-R/5 9034 P-050/5 9034-032/5

1 K ? N 5 4
l/min. db (A) LpA
9034 P-2 160 99 86.7 400 218288
Reciprocating sabre saw blade for sabre saw
9034P-2 and cordless reciprocating saw 9234
• 5 pieces per package
• 18 teeth/inch, bevelled, corrugated teeth
• For all metals including non-iron pipes, sheets and
stainless steel, material thickness 1.5 – 3 mm
• Total length: 153 mm
1 K ? ^ N 5 4 • Width 19 mm
rpm
l/min.
9035 G-1 150 28.31 13000 db (A) LpA 220 246625 • Thickness 1 mm
78
• Bi-metal
9034 P-R/5 153 – – 175 218318
File set
9034 P Sabre saw For sabre saw 9034 P-2
• 5 pieces per package
• Increased efficiency with reduction of weight, air consumption, A/ • Contents:
noise generation and vibration 1 round file
1 triangular file
1 half-round file
• Direction of air exhaust adjustable 1 flat file
• Suitable for cutting small radii 1 square file
• Cutting capacity aluminium: 4 mm • Suitable for numerous materials
• Cutting capacity sheet steel: 3 mm • Total length: approx. 135 mm
• Strokes/min.: 9500 • Shank diameter: 4 mm
• Particularly suitable for cleaning sensor modules etc., 9034 P-050/5 135 – – 115 218349
due to file blade socket (included in delivery)
Contents: Saw blades
1 sabre saw For sabre saw 9034-1 ∙ 9034P-1 ∙ 9034P-2
3 saw blades, 18 / 24 / 32 teeth each (overall length: 93 mm) • 5 pieces per package
1 reciprocating saw blade, 18 teeth (overall length: 153 mm) • 93 mm total length
5 files (overall length: ~135 mm) • Socket 1 x 13 mm
1 inside hexagon wrench (in the handle) • 18 teeth
1
• Air connection inlet: inside thread 12.91 mm ( ⁄4″) 9034 P-018/5 93 – – – 225958
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm Saw blades
For sabre saw 9034-1 ∙ 9034P-1 ∙ 9034P-2
• Working pressure (bar): 6.3 • 5 pieces per package
• Sound power level: 97.7 db(A) Lp W • 93 mm total length
• Vibration acceleration: 6.13 m/s 2 • Socket 1 x 13 mm
• Saw stroke: 10 mm
• 24 teeth
9034 P-024/5 93 – – – 225965
Saw blades
For sabre saw 9034-1 ∙ 9034P-1 ∙ 9034P-2
• 5 pieces per package
• 93 mm total length
• Socket 1 x 13 mm
• 32 teeth
B 9034 P-032/5 93 – – – 225989
364 Errors excepted Components and spare parts from page 500 to 509
