Pneumatic tools ∙ Cordless tools

Drilling and grinding machines

9033 Mini right-angle grinder 9033 Mini polisher

• Heavy-duty multi-bearing gearbox with a 2.5-times longer service A/ • Heavy-duty multi-bearing gearbox with a 2.5-times longer A/
life compared to conventional gearboxes service life compared to conventional gearboxes
• Optimised for spot repairs
• Application: Handy and light tool for working in areas with difficult access
• For grinding wheels: 50 – 59 mm • Application: For working in areas with difficult access and repair work
• For grinding wheel thickness: 1 – 4 mm • Extremely light, handy tool
• Adjustable protection cover • Grinding disc diameter: 50 mm
3
• Spindle thread: ⁄8 inch 24 UNF • Grinding disc thread: ⁄16 inch UNF
5
• Exhaust air is guided through the handle • Exhaust air is guided through the handle
1
1
• Air connection inlet: inside thread 12.91 mm ( ⁄4″) • Air connection inlet: inside thread 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included) • Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm • Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3 • Working pressure (bar): 6.3
• Sound power level: 96.8 db(A) Lp W • Sound power level: 94.4 db(A) Lp W
• Vibration acceleration: 1.90 m/s 2 • Vibration acceleration: 1.90 m/s 2
• Power in watts: 224 watts • Power in watts: 224 watts
• Cold insulated handle • Cold insulated handle

YouTube Clip
YouTube Clip

9033-5-01/10 9033-5-02/10 9033-5-03/10

9033 M-07/10

1 ? ^ N 5 è 4
rpm
9033 M-7 l/min. 18000 db (A) LpA 530 – 227242 9033-5-08/10 9033 M-9-010 9033 M-9-011
85.8
84
• 10 cut-off wheels 50 x 1 x 10 mm
• For steel and stainless steel
• Maximum cutting speed 100 m/s
9033 M-07/10 – – – – 10 229680
9033 M-9-01

1 ? ^ N 5 4
rpm
84
83.6
9033 M-9 l/min. 4500 db (A) LpA 600 227235
• 10 spare grinding pads, 320 grain size, x 50 mm
9033-5-01/10 – – – 10 160525
• 10 spare grinding pads, 400 grain size, x 50 mm
9033-5-02/10 – – – 7 160730
• 10 spare grinding pads, 600 grain size, x 50 mm
9033-5-03/10 – – – 18 160747
• 10 spare grinding pads, 800 grain size, x 75 mm
9033-5-08/10 – – – – 228317
• Spare polishing disc, x 50 mm
9033 M-9-01 – – – – 228362
• 5 spare polishing pads, flat, x 50 mm
9033 M-9-010 – – – – 228324
• 5 spare polishing pads, curved, x 50 mm
9033 M-9-011 – – – – 228331

Components and spare parts from page 500 to 509 Errors excepted 361
