Pneumatic tools ∙ Cordless tools Pneumatic tools ∙ Cordless tools

Drilling and grinding machines Drilling and grinding machines

9033 Mini disc sander ∙ angled 9033 Mini disc sander ∙ angled

• Heavy-duty multi-bearing gearbox with a 2.5-times longer A/ C A/
service life compared to conventional gearboxes
• Optimised for spot repairs
• Application: For processing surfaces even in hard to reach work areas, e.g. for
removing rust, stripping paint, removing adhesive and sealing residues, as well as
for cleaning/processing surfaces, weld seams, etc. using various abrasive media
®
• Roloc quick-change system:
Combine with many abrasive media
Fast, tool-free, easy change of abrasives
• Grinding disc diameter: 50 mm
• Grinding disc thread: ⁄4 inch– 20 UNF 1 5 è 4
1
?
N
^
• Exhaust air is guided through the handle l/min. rpm db (A) LpA
• Air connection inlet: inside thread 12.91 mm ( ⁄4″) Strip wheel set, 4 pieces
1
• Coupler plug: Nominal size 7.2 (included) For work on tough surfaces
• Hose diameter (recommended): 10 mm • Hard variant
• Working pressure (bar): 6.3 • For rust removal, paint stripping, cleaning welding seams,
• Sound power level: 95.2 db(A) Lp W removing severe surface contamination and coatings
• Vibration acceleration: 1.80 m/s 2 • For stainless steel, FE metal, non-ferrous metal, aluminium
• Power in watts: 224 watts as well as workpieces such as sheets, pipes, weld seams
• Cold insulated handle • Use on larger surfaces
• High edge strength
• High durability
• Set consisting of 4 discs
• Reinforced Clean + Strip construction
• Tough nylon fibre fleece
• Coarse fibre fleece construction
• Roloc quick-change system for quick, tool-free assembly
®
• Diameter: 50.8 mm
• Recommended rpm: 8000 – 10000
• Max. rpm: 18000
9033-11-020/4 – – – – – 222834
• 5 pieces Abrasive material, blue, x 50 mm, 300 grain size
• Base component: nylon, abrasive: resin
®
• Roloc connection
9033-11-0300/5 – – – – 5 228263
Strip wheel set, 4 pieces
For work on tough surfaces
• Soft variant
• Flexible coarse cleaning disc for universal cleaning
applications for use on larger surfaces
• Set consisting of 4 discs
YouTube Clip • Reinforced Clean + Strip construction
• Tough nylon fibre fleece
• Open fleece structure
®
• Roloc quick-change system for quick, tool-free assembly
• Diameter: 50.8 mm
• Recommended rpm: 8000 – 10000
• Max. rpm: 18000
9033-11-030/4 – – – – – 222728
9033-11-020/4 9033-11-030/4 9033-11-036/2 9033-11-050/2
Replacement bristle grinder set, purple, 2 pieces
For cleaning and gentle deburring
• Consistent results and cleaning effect throughout the entire
service life as no pressure is applied when working
• Roloc quick-change system for quick, tool-free assembly
®
• Solid plastic brush offset with ceramic grit
• Adapts to contours and shape of the workpiece
9033-11-080/5 9033-11-0120/2 9033-11-0150/5 9033-11-0300/5 • Bristle length: approx. 16 mm
• Max. rpm: 25000
• Diameter: 50 mm
• Grain size: 36
9033-11-036/2 – – – – – 222872
9033-11-S 060 • 5 pieces Abrasive material, brown, x 50 mm, 80 grain size
9033-11-S 080 • Base component: nylon, Abrasive: resin
9033-11-S 120 9033 M-11-015 ®
• Roloc connection
9033-11-080/5 – – – – 5 228270
Replacement bristle grinder set, green, 2 pieces
For cleaning and gentle deburring
1 ? ^ N 5 è 4 • Consistent results and cleaning effect throughout the entire
rpm
service life as no pressure is applied when working
84
9033 M-11 l/min. 18000 db (A) LpA 440 – 227129 • Roloc quick-change system for quick, tool-free assembly
84.2
®
• 1 piece Replacement grinding disc • Solid plastic brush offset with ceramic grit
1
• Roloc connection with ⁄4 inch UNF thread (inside thread) • Adapts to contours and shape of the workpiece
®
9033 M-11-015 – – – – – 228355 • Bristle length: approx. 16 mm
• 5 pieces Abrasive material, red, x 50 mm, 150 grain size • Max. rpm: 25000
• Base component: nylon, Abrasive: resin • Diameter: 50 mm
®
• Roloc connection • Grain size: 50
9033-11-0150/5 – – – – 5 228256 9033-11-050/2 – – – – – 222865
B B
362 Errors excepted Components and spare parts from page 500 to 509
