Pneumatic tools ∙ Cordless tools Pneumatic tools ∙ Cordless tools

Drilling and grinding machines Drilling and grinding machines

9032 Mini die grinder ∙ angled 9033 Orbital sander

• Heavy-duty multi-bearing gearbox with a 2.5-times longer service life / C /
compared to conventional gearboxes
• Application: Lightweight, handy device for grinding,
polishing, burnishing and deburring 1 ? ^ N 5 4
• Angled design for working in tight areas l/min. rpm db (A) LpA
• Exhaust air is guided through the handle 9033-2 57 12000 88.8 900 156337
• Air connection inlet: inside thread 12.91 mm ( ⁄4″) Grinding pads
1
• Coupler plug: Nominal size 7.2 (included) For orbital sander 9033-1 and -2
• Hose diameter (recommended): 10 mm 6 holes
• Working pressure (bar): 6.3 For metalworking. x 150 mm.
Pack contents 10 pieces
• Sound power level: 92.9 db(A) Lp W Grain size 80
• Vibration acceleration: 5.10 m/s 2 9033-180/10 – – – 161 139330
• Collet chuck: 6 mm Grain size 100
• Power in watts: 224 watts
• Cold insulated handle 9033-1100/10 – – – 133 139347
Grain size 120
9033-1120/10 – – – 139 139354
Grain size 150
9033-1150/10 – – – 123 139361
15-hole grinding disc
For Orbital sander 9033-2
• Medium hard with fiber-reinforced rear side
• With hook and loop fastener
5
• x 150 mm with ⁄16″ thread
9033-020 – – – 170 156351
9033 Belt sanders

• Continuous speed regulation via speed regulator on back of A/
handle
• Application: For narrow surfaces (belt width 10 mm)
• Locking device for quick belt changing
YouTube Clip • For abrasive belts 10 x 330 mm
• Automatic belt adjustment
1 ? ^ N 5 è 4 • Fine adjustment of belt
rpm
9032 M-5 l/min. 18000 db (A) LpA 480 – 227105 • 360° rotatable belt run
84
81.9
• Belt speed: 1370 m / min
• Collet chuck x 3 mm • Incl. hex-head wrench for fine adjustment of the
• For 9032Lg-1 ∙ 9032M ∙ 9032M-1 ∙ 9032M-5 ∙ 9032N-1 ∙ 9032N-5 ∙ 9032P-1 belt and angle setting in the handle
1
9032-03 S – – – – – 228928 • Air connection inlet: inside thread 12.91 mm ( ⁄4″)
• Set with 3 different milling cutters (6 mm shaft) in • Coupler plug: Nominal size 7.2 (included)
cylindrical, tapered and spherical shape • Hose diameter (recommended): 10 mm
• Head diameter (cylindrical shape): 10 mm • Working pressure (bar): 6.3
• Head diameter (spherical shape): approx. 9 mm • Sound power level: 94.8 db(A) Lp W
9032-06/3 – – – – 3 222667 • Vibration acceleration: 1.88 m/s 2
• Power in watts: 417.6 watts
• Cold insulated handle
9033 Orbital sander
• Dust extraction /
• Suction hose (2.0 m) and collection bag included
• Continuous speed regulation
• Low height and light composite housing
• Grinding disc with 15 bore holes,
x 150 mm with hook and loop fastener
• Anti-slip handle
• Air connection inlet: inside
thread 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size 7.2 (included)
• Working pressure (bar): 6.3
• Sound power level: 93.8 db(A) Lp W
• Vibration acceleration: 5.35 m/s 2
• Stroke: 5 mm
• Power in watts: 375 watts 1 ? ^ N 5 4
rpm
94
9033 N-4 l/min. 19000 db (A) LpA 810 210183
83.8
Abrasive belts
For belt sander 9033N-4
330 x 10 mm. Pack contents 10 pieces.
Grain size 80
9033-480/10 – – – 39 139101
Grain size 100
9033-4100/10 – – – 35 139118
Grain size 120
B 9033-4120/10 – – – 32 139125
356 Errors excepted Components and spare parts from page 500 to 509
