Pneumatic tools ∙ Cordless tools Pneumatic tools ∙ Cordless tools

Drilling and grinding machines Drilling and grinding machines

9032 Die grinder ∙ straight design 9032 Die grinder ∙ angled
C
• Lightweight, handy device for grinding, polishing, burnishing and / /
deburring
• Straight design
• Stepless speed regulation via setting wheel on the top of the device
• 360° exhaust (adjustable)
1
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3
• Sound power level: 85 db(A) Lp W
• Vibration acceleration: 0.40 m/s 2
• Collet chuck: 6 mm
• Power in watts: 224 watts
• Cold insulated handle

9032-06/3

1 ? ^ N 5 è 4
rpm
9032 N-5 l/min. 2000 – 20000 db (A) LpA 500 – 198788
74
78
• Collet chuck x 3 mm
• For 9032Lg-1 ∙ 9032M ∙ 9032M-1 ∙ 9032M-5 ∙ 9032N-1 ∙ 9032N-5 ∙ 9032P-1
9032-03 S – – – – – 228928
• Set with 3 different milling cutters (6 mm shaft) in
cylindrical, tapered and spherical shape
YouTube Clip • Head diameter (cylindrical shape): 10 mm
• Head diameter (spherical shape): approx. 9 mm
9032-06/3 – – – – 3 222667
9032 Die grinder ∙ straight design

• Extremely powerful device (700 watts) /
9032-06/3
• Application: Grinding, polishing, burnishing and deburring
1 ? ^ N 5 è 4 • Straight design
l/min. rpm db (A) LpA • Air connection inlet: inside thread 12.91 mm ( ⁄4″)
1
9032 N-1 74 2000 – 25000 79 400 – 189359 • Coupler plug: Nominal size 7.2 (included)
• Collet chuck x 3 mm • Hose diameter (recommended): 10 mm
• For 9032Lg-1 ∙ 9032M ∙ 9032M-1 ∙ 9032M-5 ∙ 9032N-1 ∙ 9032N-5 ∙ 9032P-1 • Working pressure (bar): 6.3
9032-03 S – – – – – 228928 • Sound power level: 98 db(A) Lp W
• Set with 3 different milling cutters (6 mm shaft) in • Vibration acceleration: 0.46 m/s 2
cylindrical, tapered and spherical shape • Collet chuck: 6 mm
• Head diameter (cylindrical shape): 10 mm • Power in watts: 700 watts
• Head diameter (spherical shape): approx. 9 mm • Cold insulated handle
9032-06/3 – – – – 3 222667

9032 Die grinder ∙ angled
• Sanding, buffing, polishing and deburring, particularly in areas that are /
difficult to access
• Angled design
• Stepless speed regulation via setting wheel on the top of the device
• 360° exhaust (adjustable)
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm
• Working pressure (bar): 6.3 YouTube Clip
• Sound power level: 82 db(A) Lp W
• Vibration acceleration: 0.50 m/s 2
• Collet chuck: 6 mm
• Power in watts: 224 watts
• Cold insulated handle

9000-040

1 l/min. rpm db (A) LpA 5 è 4
^
N
?
9032 P-1 150 22000 87 800 – 190508
• Collet chuck x 3 mm
• For 9032Lg-1 ∙ 9032M ∙ 9032M-1 ∙ 9032M-5 ∙ 9032N-1 ∙ 9032N-5 ∙ 9032P-1
YouTube Clip 9032-03 S – – – – – 228928
B B
354 Errors excepted Components and spare parts from page 500 to 509
