Pneumatic tools ∙ Cordless tools

Air blow tools

9040 Air blow gun ∙ 100 mm ∙ 9040 Air blow gun ∙ 100 mm ∙ with
quiet ∙ with bent pipe Venturi nozzle and bent pipe
• Extreme reduction of noise C
• Strong blowing force
• Non-blocking
• Application: Fast removal of shavings or other foreign
objects, especially in areas that are difficult to access
• To be used on machinery, in workshops, for wood work, hobby workshops
• Handle, trigger and valve made of acetal plastic
• Seals and O-rings made of nitrile
• Spring made of hardened spring steel
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size 7.2 (included)
• Working pressure (bar): 6
• Max. working pressure [bar]: 12 bar
• Pipe x: 8 mm
• Blast pipe and shaft made of steel
• 2003/10/CE Max 85 dB
• OSHA 1910.95 (b) Max 90 dB 8 hr YouTube Clip
• OSHA STD 1-13.1, Max 30 PSI if blocked
• Temperature range: -10°C – 80°C
1 K ? N 5 4
l/min. db (A) LpA
9040 P-4 265 235 83.7 165 209569

9040 Air blow gun ∙ quiet ∙ with wide flat nozzle

• Wide flat nozzle for cleaning surfaces
• Considerable blowing force
• Non-blocking

• Application: Fast removal of shavings or other foreign objects,
especially in areas that are difficult to access
• To be used on machinery, in workshops, for wood work, hobby workshops
• Handle, trigger and valve made of acetal plastic
• Seals and O-rings made of nitrile
• Spring made of hardened spring steel
1
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Working pressure (bar): 6
• Max. working pressure [bar]: 8 bar
• 2003/10/CE Max 85 dB
• OSHA 1910.95 (b) Max 90 dB 8 hr
• OSHA STD 1-13.1, Max 30 PSI if blocked
1 K ? N 5 4 • Temperature range: -10°C – 80°C YouTube Clip
76.8
9040 P-3 255 l/min. db (A) LpA 100 209644
245
Air blow gun ∙ 100 mm ∙ with
9040 Venturi nozzle and bent pipe

• 100% increase in air outlet quantity thanks to Venturi nozzle
• Extreme blowing force
• Non-blocking
• Application: Fast removal of shavings or other foreign
objects, especially in areas that are difficult to access
• To be used on machinery, in workshops, for wood work, hobby workshops
• Handle, trigger and valve made of acetal plastic
• Seals and O-rings made of nitrile
• Spring made of hardened spring steel
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size 7.2 (included)
• Working pressure (bar): 6
• Max. working pressure [bar]: 16 bar
• Pipe x: 8 mm YouTube Clip
• Blast pipe and shaft made of anodised steel
• OSHA 1910.95 (b) Max 90 dB 8 hr
• OSHA STD 1-13.1, Max 30 PSI if blocked
• Temperature range: -10°C – 80°C

1 K l/min. db (A) LpA 5 4
?
N
B 9040 P-5 203 450 78 95 209576
Components and spare parts from page 500 to 509 Errors excepted 369
