Pneumatic tools ∙ Cordless tools Pneumatic tools ∙ Cordless tools

Air blow tools Tyre inflators and measuring instruments

9040 2-way air blow gun 9040 Blow pen

• Choice of air supply at tool head or handle / • Practical and compact design with clip for fixation e.g. in pockets
• Application: Fast removal of chips or other foreign objects • Turn to adjust air flow
• Exchangeable nozzles: • Nozzle: 3 mm x
– Short nozzle for areas with restricted access • Easy handling, clicks directly on air coupling 7.2 mm
– Long nozzle (112 mm) with safety nozzle tip (scratch protection) • Inlet pressure: 12 bar
• Maximum pressure: 10 bar • Maximum flow rate: 360 l/min. at 6 bar
• Pressure regulator • Perbunan seal (NBR)
• To be used on machinery, in workshops, for wood work, hobby workshops • Duraluminium housing
• Aluminium housing • Coupler plug: integrated, nominal size 7.2
• Thread nozzles: /8 inch PF 28
1
(9.728 mm outside x / 0.907 mm pitch)
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size 7.2 (included)
• Working pressure (bar): 6.3
• Anti-slip, cold insulated handle

1 4
9040-3 109500

1 ? N 5 4

9040-4 l/min. db (A) LpA 205 176236
330
86
9040 LG Air blow gun ∙ long

• Increased efficiency due to Venturi nozzle (54 mm / 35 gram) /
• 90° lateral nozzle (32 mm / 8.4 gram) for cleaning cooling fins
YouTube Clip
• Application: Cleaning areas with restricted access on
vehicles, machinery and agricultural machinery
• Grip area with insulated lance to protect it from cold
• Maximum pressure: 12 bar
• Ergonomic handle
1
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm 9040 Lg-3-02 9040 Lg-3-01
• Working pressure (bar): 6.3
• Cold insulated handle

1 K l/min. 5 è 4
?
9040 LG-3/2 1085 450 313 2 206339
• Venturi nozzle for 9040-4 and 9040LG-3/2
• 100% increase in air outlet quantity thanks to Venturi effect
9040 LG-3-01 – – – – 241514
• Lateral nozzle for 9040-4 and 9040LG-3/2
• Nozzle enables lateral blow-out, e.g. for cleaning cooling fins and other hard-to-reach areas
9040 LG-3-02 – – – – 241521
370 Errors excepted Components and spare parts from page 500 to 509
