Pneumatic tools ∙ Cordless tools

Grease gun, spray gun, air blow and suction gun

9045 Soda spray gun 9048 P Wash-gun set

• Does not damage rubber, glass or plastic parts / • Cleaning without the use of aggressive chemicals or solvents
• No heating / deformation of sheets during blasting
• Application: Effective, powerful and solvent-free cleaning of e.g. cooling systems
• Application: Gentle, damage-free and environmentally friendly with graded system cleaning nozzle
cleaning and paint stripping with NaHCO3 (sodium bicarbonate) No splashback, effective cleaning of machines, units
• Application fields: and vehicle parts with jet wash nozzle
– Removing graffiti • Swivel joint at the water connection, helps to avoid “hose spaghetti”
– Facade and monument cleaning • Continuous independent regulation of water and compressed air supply
– Removing paint from wooden objects • Washing and system cleaning nozzle included
– Removing paint on glass surfaces and window frames • No splashback even when cleaning with combined
without causing damage to glass and seals water/compressed air jet at short distance
– Removing boot coatings, without attacking hull • Damage-free cleaning thanks to water / air operation
• 1 preset metal precision nozzle for optimum performance • Quick, easy and gentle cleaning
• 3 high performance wide-jet nozzles • High-quality materials
• Refillable container with 1.2 l volume • Including:
• Including 1 kg soda blast-cleaning agent – Water connection variants: 13 mm (1/2″) nipple for water coupling
• Handle, trigger and valve made of acetal plastic (Gardena system compatible) or 20 mm (3/4″) GHT thread
• Seals and O-rings made of nitrile – Graded system cleaning nozzles
• Spring made of hardened spring steel – Jet washing nozzle
• Container made of PEHD • Working pressure (bar) air: 6-10
• Air connection inlet: inside thread 12.91 mm ( ⁄4″) • Temperature range -10 / +40 °C
1
• Coupler plug: Nominal size 7.2 (included) • Recommended air hose diameter: 10 mm
• Working pressure (bar): 6.3 • Recommended water hose diameter: 13 mm
• Air connection inlet: inside thread 12.91 mm ( ⁄4″)
1
• Coupler plug: Nominal size 7.2 (included)
• Hose diameter (recommended): 10 mm

YouTube Clip

1 ? 5 4
9045 P-5 S
200
9048 P-2/3 l/min. 400 234608

1 K ? 5 4
l/min.
9045 P-1 247 180 460 209590
• Sodium bicarbonate
• Application
– Material-friendly removal of paints, contaminants, etc.
– Stripping of car body parts and cleaning of components
careful removal of graffiti as well as for facades and cleaning landmarks
– Cleaning mouldings and extruder tools
• 5 l canister with carrying handle
• Optimal flow properties
• Angular powder with medium grain size ~ 25 μm³
9045 P-5 S – – – 210404

Components and spare parts from page 500 to 509 Errors excepted 373
