Page 376 - HAZET哈蔡特2024英文样本

Pneumatic tools ∙ Cordless tools Pneumatic tools ∙ Cordless tools

Pneumatic adaptors Pneumatic adaptors

Pneumatic adaptors

9040 Spiral hose 9040 Spiral hose

• High flexible polyurethane hose with length of 7.62 m and 6.35 mm inside x • High flexible polyurethane hose with length of 7.62 m and 10 mm inside x
• Inside diameter of the hose: 6.35 mm • Application: Flexible connection of pneumatic tools
• Connecting pieces with 360° rotary joints • Inside diameter of the hose: 10 mm
• Burst pressure according to DIN: 55.1 bar / 800 PSI • Connecting pieces with 360° swivel joints
• Working pressure: 10 bar • Burst pressure according to DIN: 60 bar
• Air connection inlet: inside thread 12.91 mm ( ⁄4″), coupler plug • Working pressure: 10 bar
1
7.2 mm type 1 (DE/AT/SI/HU/CN/IN/PT/RU/PL/RO/TR) • Air inlet thread: ⁄8″
3
• Air connection outlet: outside thread 12.91 mm • Working length: 50% to 80% of the hose length
1
( ⁄4″), coupler bushing 7.2 mm type 1 • 100% silicone-free EPDM VK60FA
• Coupler plug: Nominal size 7.2 (included) • Maximum flexibility
• Hose length: 7.62 m • Highly abrasion-resistant
• Dimensional stable
3
• Air connection inlet: outside thread 16.41 mm ( ⁄8″)
3
• Air connection outlet: outside thread 16.41 mm ( ⁄8″)
• Hose length: 7.62 m
• Temperature range: -20°C – 60°C

1 5 4 1 4
9040-7 630 153404 9040 S-10 212361

9040 Hose reel

• Hose stop with “Stop at any point” function
• Neat winding of the hose thanks to automatic guidance
• Braked winding to prevent risk of accidents
• Application: Automatic hose reel offers tidiness in the workshop –
hose not left lying around, thus reducing the risk of accidents
• Inside diameter of the hose: 10 mm
• Suitable for compressed air or water
• Dimensions: 459 x 378 x 205 mm
• Dimensions (packed): 465 x 400 x 220 mm
• Hybrid polymer hose, black
• Length of connection hose: 0.9 m
• Integrated drill template for mounting on cardboard packaging
• Thread BSPT
• Meets all relevant requirements defined in the European
Directives for Machinery 2006/42/EC
• Optionally usable with HAZET safety coupling 9000-061
• Closed special plastic case, supplied with rotating metal mounting
bracket made for separate installation at the workplace
• Borehole spacing of the mounting bracket: 186 mm
• Air connection inlet: outside thread 16.41 mm ( ⁄8″)
3
• Air connection outlet: outside thread 16.41 mm ( ⁄8″)
3
• Hose length: 15 m
• Max. working pressure [bar]: 20 bar
• Temperature range: -40°C – 60°C
YouTube Clip

1 5 4
9040 N-10 6450 206445
374 Errors excepted Components and spare parts from page 500 to 509
