Crimpers

Tele-TitanXg 2.0 Modular Plug Crimp Tool
™
The next generation in our 10Gig Termination System combines two crimpers into a single tool, making 2-step
crimping simple. Insert the connector into the front end to terminate the contacts and switch to the back end to crimp
the external ground. Like the original, the new Tele-TitanXg 2.0, along with our 10Gig Shielded Connectors, are
engineered specifically for Cat6A cables to provide true 10Gig performance each and every time. Cat6A 10Gig Shielded RJ45
Connectors: page 49
Features
• One tool does the job of two tools
• Improve efficiencies by not having to change
out tools in the middle of your termination The Cat6A 10Gig
Crimp External Ground
• Straight action crimp achieved with minimal Termination
hand force Solution!
• Compact and rugged design
• Terminates to industry specified crimp heights
• Gun-style lock for secure closure
• Non-slip handle and finger grooves for
comfortable grip and control
• Not to be used on standard RJ45 modular plugs

Application
• RJ45 Cat6A 10Gig Shielded RJ45 connectors
• Cat6E, Cat6A, Cat7, and over-sized Cat5e/6 Industrial Ethernet Cables
• RJ12/11 connectors

Part # Description
12516C Tele-TitanXg 2.0 Crimp Tool
™
12517C Tele-Titan Xg 2.0 Combo 10-Pack
™

Tele-TitanXg Modular Plug Crimp Tool
™
This professional crimp tool fits comfortably in your hand or your pocket. The straight
action termination delivers even pressure on each of the modular plug’s pins ensuring precise
termination. Its superior fit and function consistently meet your performance requirements.
Cat6A 10Gig Shielded RJ45
Connectors: page 49
Features
• Specifically designed for RJ45 Cat6A 10Gig shielded
connectors (Not for standard RJ45 modular plugs)
• Minimal hand force
• Straight action crimp
• Compact and rugged
• Terminates to industry specified crimp heights
• Stays securely closed with gun-style lock
• Built-in cable stripper for round wire and flat satin
• Easily control the blade depth when stripping
• Built-in cable cutter
10Gig Termination Kit ™
Part # Description Kit includes the Tele-TitanXg and 10Gig
12515C Tele-TitanXg Modular Plug Crimp Tool shielded connectors. The pairing that assures
™
12507BLC Replacement Blade Set for you will achieve 10Gig performance every time.
P/N 12515C P/N 90170, see Kits page 90.
