Strippers
We Make Connections EZ!

ProStrip 25R Coax Stripper
Designed for the professional contractor. Factory preset for industry standard 1/4" cable .25"
preparation, eliminating the need for time consuming blade depth adjustments. Stainless
steel rollers provide smoother, concentric, non-binding rotation on a wide range of cables
for fast, professional results. No adjustments required!

Features
• Includes 2 stripping ports for a broader range of cables:
– RG6 and RG59
– RGB/Mini 59 for 23, 24, and 25 AWG
• Industry standard ¼" strip length
• Preset, quick-change blade cartridges
• Rugged, high impact plastic housing
• Long life stainless steel blades 15029C

Part # Description
15028C ProStrip 25R Coax Stripper
15029C Replacement Blade Cartridge for P/N 15028C
Stainless Steel Rollers

E Series Coax Cable Strippers Features
The E Series Coax Cable Strippers are simple to operate and ensure a • Works with RG58/59/62/6/6 Quad coax cables
professional, repeatable strip every time. All strippers include a hex
wrench for adjustable blade depth. Stripping lengths are also adjustable. • Adjustable stripping depth for various insulation
types and thicknesses
A • Preset for 6mm (referred to as the ¼" strip) but
adjusts to additional dimensions
2-Level Stripping • Uses drop-in replacement blades, no cassettes required
• Factory presetting: Shield dimension (A) 6mm (0.236") • Hex wrench snaps into housing for convenient storage
• Adjustable to additional settings: 4, 8, and 12mm
(0.157 / 0.315 / 0.472") • Molded from high impact plastic for long life
Part # Description
15030C Coax Cable Stripper, 2-Level RG58/59/62/6/6Q
15038C Replacement Blades (2), for 2-Level Strippers

A B

3-Level Stripping
• Factory presetting: Shield Dimension (A) 8mm (0.315”);
Dielectric (B) 4mm (0.157”) 15030C
Part # Description
15033C Coax Cable Stripper, 3-Level RG58/59/62 2-Level Adjustment
15034C Coax Cable Stripper, 3-Level RG59/62/6/6Q
15035C Coax Cable Stripper, 3-Level RG7/8/11/213/214
15039C Replacement Blades (2), for 3-Level Strippers
3-Level Adjustment

www.platinumtools.com See Page 106 For Warning Information 15
