Strippers

Slit & Ring Fiber Optic Cable Stripper
Designed to slit and ring cables, buffer tubes and jackets on fiber optic
cables with diameter ranges of 1.2mm to 6.4mm. Intentionally made to
be light and small, making it easy to use in confined spaces.

Features
• Slitting V-block is removable and reversible to accommodate
various diameters
• Slit and ring strippping range: 1.2mm – 6.4mm
• Adjustable slit blade and ring blade for exact strip cut depth
Part # Description
15062C Slit & Ring Fiber Optic Cable Stripper
15063C Replacement Blade Set

Adjustable Fiber Optic Stripper
Fiber Jacket Strip The Adjustable Fiber Optic Stripper is designed to be versatile and economical
without compromising the needs of the professional installer. All stripping
Fiber Buffer/ surfaces are precision ground and hardened for durability and long life. The
Coating Strip circular notch strips a full range of outer fiber cable jacket insulations. The
V-notch will strip/remove a full range of fiber buffer and coating materials. The
adjustment screw allows for precise adjustments and locks into place once set.
Features (See diagram)

• Use V-notch for stripping 250μ to 500μ fiber coatings (A)
• Use V-notch for stripping 500μ to 900μ tight buffer.
Locking (Loose Tube to 1500μ) (B)
Adjustment
Screw • Use round notch for stripping
outer cable jacket insulations
to 3.0mm diameter (C) A B Kevlar C
Part # Description • Cushioned grip handles provide positive, non-slip, comfortable operation
15060C Adjustable Fiber Optic Stripper

5-in-1 Fiber Optic Stripper
Work with a multitude of fiber optic cables. The pre-set design ensures all cavities Part # Description
are precision set and no adjustments needed, great for working in the field. 15061C 5-in-1 Fiber Optic Stripper

Features
• Use for stripping multitude of fiber optic cables
• Cushioned grip handles provide positive
non-slip, comfortable operation
• Precision ground stripping cavities
• Factory set and calibrated
• Strips outer jacket from 2.0 – 2.4mm fiber,
2.8 – 3.0mm fiber and 2.0 – 3.0mm
loose tube buffer tubes
• Strips 900mm buffer and 250mm
acrylate coating

12 See Page 106 For Warning Information Phone: 800.749.5783 Fax: 800.749.5784
