Torque Wrench Fittings QOH Series -
Square Drive Open Box End

Series QOYH Model Fohmjti
ovaTork

Item No. Ring Size Opening Shark Size A H D Weight Item No. Ring Size Opening Shark Size A H D Weight
Size mm mm mm mm mm g Size mm mm mm mm mm g
QOYH98 1/4" 6.35 9x12 17.5 8 22 55 QOYH1428 7/8" 17 14x18 25 16 37 155
QOYH910 5/16" 5.9 9x12 17.5 12 22 63 QOYH1430 15/16" 18.3 14x18 25 16 40 155
QOYH912 3/8" 6.8 9x12 17.5 12 22 63 QOYH1432 1" 19.3 14x18 25 16 41 155
QOYH914 7/16" 8.5 9x12 17.5 12 22 62 QOYH1434 1 1/16" 20 14x18 30* 16 44 155
QOYH916 1/2" 9.8 9x12 17.5 12 25 63 QOYH1436 1 1/8" 21.2 14x18 35* 16 48 155
QOYH918 9/16" 11.2 9x12 17.5 13 27 62 QOYH1438 1 3/16" 22.1 14x18 35* 16 48 155
QOYH920 5/8" 13 9x12 17.5 13 30 69 QOYH1440 1 1/4" 23.4 14x18 35* 16 51 155
QOYH1422 11/16" 14.4 14x18 25 15 33 150 QOYH1442 1 5/16" 24.5 14x18 35* 16 51 155
QOYH1424 3/4" 15.9 14x18 25 15 34.5 150 QOYH1452 1 5/8" 41.28 14x18 50* 16 65 180
QOYH1426 13/16" 15.9 14x18 25 16 35.5 155 * marks are special fittings, you should adjust the torque according to torque wrench
manual
