Torque Wrench Fittings QH Series - Square Drive Box End

Ring size Shank Size A H D Weight Ring size Shank Size A H D Weight
Item No. Item No.
mm mm mm mm mm g mm mm mm mm mm g
Series QH1450 50 14x18 40* 19 70 230 QH2455 55 24x32 55* 25 102 1533
ovaTork QH1455 55 14x18 45* 19 76 250 QH2460 60 24x32 60* 25 110 1642
25
116
QH2465
65
1900
65*
24x32
19
255
84
60
14x18
45*
QH1460
QH1465 65 14x18 50* 19 90 265 QH2470 70 24x32 65* 25 120 1950
QH1470 70 14x18 55* 19 96 270 QH2475 75 24x32 65* 25 120 1950
QH1475 75 14x18 60* 19 100 285 QH2485 85 24x32 80* 25 150 2500
QH1480 80 14x18 65* 19 108 310 QH2727 27 27x36 50 28 62 1190
QH2419 19 24x32 35 25 42 630 QH2730 30 27x36 50 28 70 1190
QH2420 20 24x32 35 25 46 630 QH2731 31 27x36 50 28 70 1213
QH2422 22 24x32 35 25 46 730 QH2732 32 27x36 50 28 70 1213
QH2424 24 24x32 35 25 48 880 QH2734 34 27x36 50 28 72 1235
QH2736 36 27x36 50 28 72 1225
QH2427 27 24x32 35 25 50 910
QH2738 38 27x36 50 28 75 1263
QH2428 28 24x32 35 25 52 910
QH2741 41 27x36 50 28 76 1265
QH2430 30 24x32 35 25 55 945
QH2742 42 27x36 50 28 76 1265
QH2432 32 24x32 35 25 57 961
QH2433 33 24x32 35 25 59 961 QH2745 45 27x36 50 28 80 1270
QH2746 46 27x36 50 28 82 1270
QH2434 34 24x32 35 25 61 977
QH2750 50 27x36 50 28 92 1603
QH2436 36 24x32 40* 25 62 1050
QH2755 55 27x36 55* 28 104 1771
QH2437 37 24x32 40* 25 65 1060
Nfusjd QH2760 60 27x36 60* 28 110 1874
QH2438 38 24x32 40* 25 65 1053
QH2440 40 24x32 45* 25 70 1056 QH2765 65 27x36 60* 28 118 2050
QH2770 70 27x36 65* 28 128 2322
QH2441 41 24x32 45* 25 73 1059
QH2775 75 27x36 75* 28 138 2600
QH2442 42 24x32 45* 25 78 1059
QH2780 80 27x36 80* 28 148 2900
QH2446 46 24x32 45* 25 82 1074
QH2785 85 27x36 80* 28 150 2900
QH2448 46 24x32 45* 25 92 1300
* marks are special fittings, you should adjust the torque according to
QH2450 50 24x32 50* 25 95 1315
torque wrench manual
QYH Model Fohmjti
Shank Size A H D Weight Shank Size A H D Weight
Item No. Ring Size Item No. Ring Size
mm mm mm mm g mm mm mm mm g
QYH98 1/4" 9x12 17.5 8 22 43 QYH1436 1 1/8" 14x18 30* 17.5 44 165
QYH910 5/16" 9x12 17.5 8 22 42 QYH1440 1 1/4" 14x18 30* 17.5 47.5 168
QYH912 3/8" 9x12 17.5 9 22 48 QYH1444 1 3/8" 14x18 30* 19 51 170
QYH914 7/16" 9x12 17.5 9 22 47 QYH1446 1 7/16" 14x18 30* 19 53 196
QYH916 1/2" 9x12 17.5 12 22 53 QYH1452 1 3/8" 14x18 35* 19 61 190
QYH918 9/16" 9x12 17.5 12 23 52 QYH1458 1 13/16" 14x18 50* 19 70 225
QYH920 5/8" 9x12 17.5 13 27 56 QYH2430 15/16" 24x32 35 25 48 880
QYH922 11/16" 9x12 17.5 13 27.5 58 QYH2436 1 1/8" 24x32 35 25 52 945
QYH924 3/4" 9x12 17.5 13 31 57 QYH2440 1 1/4" 24x32 35 25 57 960
QYH926 13/16" 9x12 17.5 13 33 68 QYH2446 1 7/16" 24x32 40* 25 62 973
QYH928 7/8" 9x12 17.5 13 34.5 73 QYH2452 1 5/8" 24x32 45* 25 73 1254
QYH942 15/8" 9x12 30* 13 48 100 QYH2458 1 13/16" 24x32 45* 25 82 1074
QYH148 1/4" 9x12 25 11 32 110 QYH2464 2 " 24x32 50* 25 95 1315
QYH1412 3/8" 9x12 25 11 32 110 QYH2470 2 3/16" 24x32 55* 25 102 1533
QYH2740 1 1/4" 24x32 50 28 70 1213
QYH1416 1/2" 14x18 25 11 32 125
QYH2748 1 1/2" 27x36 50 28 75 1263
QYH1418 9/16" 14x18 25 11 32 123
QYH2752 1 5/8 " 27x36 50 28 76 1265
QYH1420 5/8" 14x18 25 12 32 128
QYH2754 1 11/16" 27x36 50 28 76 1265
QYH1422 11/16" 14x18 25 12 32 133
QYH2758 1 13/16" 27x36 50 28 82 1270
QYH1424 3/4" 14x18 25 12 32 138
QYH2766 2 1/16" 27x36 55* 28 104 1603
QYH1426 13/16" 14x18 25 15 33 148
QYH2770 2 3/16" 27x36 55* 28 104 1771
QYH1428 7/8" 14x18 25 15 35 154
QYH2776 2 3/8" 27x36 60* 28 110 1874
QYH1430 15/16" 14x18 25 15 37.5 153
QYH2782 2 9/16" 27x36 60* 28 118 2050
QYH1432 1" 14x18 25 15 39 160
* marks are special fittings, you should adjust the torque according to
QYH1434 1 1/16" 14x18 30* 17.5 41.5 160
torque wrench manual
