Torque Wrench Fittings OH Series - Square Drive Open End

Opening Size Shank Size A H D Weight Opening Size Shank Size A H D Weight
Item No. Item No.
mm mm mm mm mm g mm mm mm mm mm g
OH2770 70 27x36 70* 28 142 1465 OH2790 90 27x36 90* 28 176 2900
OH2775 75 27x36 75* 28 148 1780 OH2795 95 27x36 95* 28 180 3000
OH2780 80 27x36 80* 28 158 2600 OH27100 100 27x36 100* 28 195 3150
OH2785 85 27x36 85* 28 164 2850 * marks are special fittings, you should adjust the torque according to
torque wrench manual
OYH Model Fohmjti

Opening Shank Size A H D Weight Opening Shank Size A H D Weight
Item No. Item No.
Size mm mm mm mm g Size mm mm mm mm g
OYH94 1/8" 9x12 17.5 5.5 22 38 OYH1450 1 9/16 " 14x18 50* 14 84 430
OYH96 3/16" 9x12 17.5 5.5 22 38 OYH1452 1 5/8" 14x18 50* 14 90 430
OYH97 7/32" 9x12 17.5 5.5 22 38 OYH1454 1 11/16" 14x18 50* 14 90 430
OYH98 1/4" 9x12 17.5 5.5 22 38 OYH1456 1 3/4" 14x18 50* 14 100 595
OYH910 5/16" 9x12 17.5 5.5 22 37 OYH1458 1 13/16" 14x18 50* 14 100 595
OYH912 3/8" 9x12 17.5 6 25 43 OYH1460 1 7/8" 14x18 50* 14 100 610
OYH914 7/16" 9x12 17.5 6 25 42 OYH1462 1 30/32 " 14x18 50* 14 100 610
OYH1464 2" 14x18 55* 14 106 600
OYH916 1/2" 9x12 17.5 7 29 47
OYH1468 2 1/8" 14x18 55* 14 116 585
OYH917 17/32" 9x12 17.5 8 33 58
OYH918 9/16" 9x12 17.5 8 33 57 OYH1470 2 3/16" 14x18 60* 14 121 650
OYH1472 2 1/4" 14x18 60* 14 121 650
OYH920 5/8" 9x12 17.5 8 38 56
OYH1476 2 3/8" 14x18 60* 14 121 650
OYH922 11/16" 9x12 17.5 8 38 80
OYH1488 2 3/4" 14x18 70* 14 135 700
OYH924 3/4" 9x12 25* 8 42.5 75
OYH1492 2 7/8" 14x18 70* 14 138 710
OYH926 13/16" 9x12 25* 8 48 100
OYH2420 5/8" 24x32 35 25 62 650
OYH928 7/8" 9x12 25* 8 48 95
OYH2424 3/4" 24x32 35 25 65 680
OYH930 15/16" 9x12 25* 8 53 110
OYH2428 7/8" 24x32 35 25 61 700
OYH932 1" 9x12 30* 8 57 110
OYH2429 29/32 " 24x32 35 25 61 700
OYH934 1 1/16" 9x12 30* 8 57 140
OYH2430 30/32 " 24x32 35 25 61 700
OYH936 1 1/8" 9x12 35* 8 57 145
OYH2431 31/32 " 24x32 35 25 61 700
OYH940 1 1/4" 9x12 35* 8 70 145
OYH2432 1 " 24x32 35 25 61 700
OYH942 1 5/16 " 9x12 35* 8 70 145
OYH2434 1 1/16 " 24x32 35 25 66.5 710
OYH944 1 3/8" 9x12 35* 8 80 145
OYH2436 1 1/8" 24x32 35 25 68 719
OYH946 1 7/16" 9x12 40* 8 80 145 OYH2438 1 3/16 " 24x32 35 25 68.5 720
OYH948 1 1/2" 9x12 45* 8 68 145 OYH2440 1 1/4" 24x32 35 25 68 602
OYH952 1 5/8" 9x12 45* 8 85 145 OYH2442 1 5/16 " 24x32 40 25 73.5 685
OYH960 1 7/8 " 9x12 55* 8 100 155 OYH2444 1 3/8 " 24x32 40 25 73.5 685
OYH148 1/4 " 14x18 25 7 30 110 OYH2446 1 7/16 " 24x32 40 25 73.5 685
OYH1414 7/16 " 14x18 25 7 30 110 OYH2448 1 1/2 " 24x32 40 25 73.5 685
OYH1416 1/2" 14x18 25 7 30 110 OYH2450 1 9/16 " 24x32 40 25 73.5 685
OYH1418 9/16" 14x18 25 8 32 115 OYH2452 1 5/8" 24x32 50* 25 86 902
OYH1420 5/8" 14x18 25 9 38 128 OYH2454 1 11/16 " 24x32 50* 25 92 1000
OYH1422 11/16" 14x18 25 9 38 127 OYH2456 1 3/4" 24x32 50* 25 92 1000
OYH1424 3/4" 14x18 25 10 42 137 OYH2460 15/8" 24x32 50* 25 103 1100
OYH1426 13/16" 14x18 25 11 48 158 OYH2464 2" 24x32 50* 25 106 1150
OYH1428 7/8" 14x18 25 11 48 155 OYH2470 2 3/16" 24x32 55* 25 104 1150
OYH1429 29/32" 14x18 25 13 51.5 159 OYH2472 2 1/4" 24x32 55* 25 120 1200
OYH1430 15/16" 14x18 25 13 51.5 159 OYH2742 1 5/16 " 27x36 50* 25 86 1338
OYH1431 31/32 " 14x18 25 13 51.5 159 OYH2748 1 1/2 " 27x36 50* 28 86 1338
OYH1432 1" 14x18 25 13 51.5 163 OYH2752 1 5/8 " 27x36 50* 28 92 1250
OYH1434 1 1/16" 14x18 30* 14 57 230 OYH2756 1 3/4 " 27x36 50* 25 92 1250
OYH1436 1 1/8" 14x18 30* 14 57 255 OYH2758 1 13/16 " 27x36 50* 28 98 1300
OYH1438 1 3/16" 14x18 30* 14 65 255 OYH2760 15/8" 27x36 50* 25 103 1350
OYH1440 1 1/4" 14x18 35* 14 65 255 OYH2770 2 3/16" 27x36 55* 25 124 1455
OYH2772 2 1/4" 27x36 55* 25 124 1455
OYH1442 1 5/16" 14x18 35* 14 75 280
OYH2776 2 3/8 " 27x36 60* 28 130 1460
OYH1444 1 3/8" 14x18 40* 14 68 365
OYH2782 2 9/16" 27x36 65* 25 136 1465
OYH1446 1 7/16" 14x18 40* 14 68 365
* marks are special fittings, you should adjust the torque according to
OYH1448 1 1/2" 14x18 45* 14 85 440
torque wrench manual
