Specialty tools

Commercial vehicles – Chassis

4937 Commercial vehicle axle nut socket 4937 Commercial vehicle centring sleeve set
set DAF ∙ RENAULT ∙ Volvo
Made in Germany 8 F
7
Made in Germany c0 F • For rim hole x 26 mm /8″- 11 G e.g. SCANIA
• Screw-in guide tube allows for flexible application
• Application: Fast assembly of centred
• j Drive 25 = 1″ or g 60 mm commercial vehicle drop centre rim G
wheels for rim hole x 26 mm
• DAF with guide tube • No damage of the thread as well as
• RENAULT ∙ Volvo without guide tube exact centring of the rims through
• With outside guide collar conically cranked bushes
• Operation with impact wrench • High fitting accuracy through
(9014MG-1 ∙ 9014MG-2) and torque precise thread production
wrench (6160-1CT ∙ 6170-1CT) • Inside thread: ⁄8″ – 11 G
7
• Precise fit • Surface: burnished
• Solid design: High (shape)
stability even with high loosening
or tightening torques
• Surface: burnished F

1 K è 4

4937-27/3 115 3 202010

4937 Commercial vehicle mounting sleeve D
MERCEDES-BENZ ∙ thread M75 x 1.5

Made in Germany F
• Mounting sleeve to protect the thread on the axle during bearing
1 N è 4 disassembly and assembly
4937-105/2 118 2 201938 • Application: Use in MERCEDES-BENZ
Atego, Atego 2, Tourino, Econic
• Only lift the approx. 40 kg bearing unit (bearing, brake
4937 MAN commercial vehicle pin disc and wheel hub) onto the mounting sleeve once, R
then push to the bearing seat with x 78 mm
wrench set for rear axle • Thread: M75 x 1.5
• Outside x: 78 mm
Made in Germany 0 F • Drive via lateral rod or without additional tools
• For MAN TGX, TGA, TGS is possible (chequered handle surface)
• Surface: burnished
• For e.g. rear axle HY 1350
• j Drive 25 = 1″ or g 60 mm
• 6 inside pins, with 11 mm width
• Inside x: 134.5 mm
• Inside x (pin-pin) 118 mm C
• Outside x 148.5 mm
• Operation possible with impact wrench (9014MG-1 ∙
9014MG-2) and torque wrench (6160-1CT ∙ 6170-1CT) 1 t 4
• Precise fit
• Precise pin geometry 4937-7578 78 201990
for ideal tool operation
in pin nuts
• Solid design: High Commercial vehicle mounting
(shape) stability even 4937
with high loosening or sleeve MAN ∙ thread M75 x 1.5 O
tightening torques
• Surface: burnished Made in Germany F
• Mounting sleeve to protect the thread on the axle during bearing
disassembly and assembly

• Application: Use with MAN TGL, TGM, L series, HL 2
• Only lift the approx. 40 kg bearing unit (bearing, brake
disc and wheel hub) onto the mounting sleeve once,
then push up to the bearing seat with x 82 mm
• Thread: M75 x 1.5
• Outside x: 82 mm A
• Drive via lateral rod or without additional tools
is possible (chequered handle surface)
• Surface: burnished

U

1 N è 4 1 t 4
4937-111/2 121 2 201945 4937-7582 82 201969
