Specialty tools

Commercial vehicles – Chassis

Chassis

Wheel bearing / Wheel hub

1790 Ball joint puller 4961 N Wheel hub grinder
G
Made in Germany C Made in Germany C/
• Application: Removing the ball joint pivots of steering arms, • Grinding pad made of aluminium with 8-point profile enables safe
steering tie rods, stabilizers etc. on heavy commercial vehicles and firm fixation of the grinding wheels
• Surface: galvanized (free from Cr 6)
• Application: Quick and easy removal of rust and dirt from contact
surfaces of wheel hubs and brake discs with wheel bolt support
• Open-pored abrasive material and cup-formed grinding
disc reduce the formation of dust to a minimum
• No formation of sparks
F

1 1 U 4

1790-3 40 85 145454
D
Made in Germany C
• Supported by hydraulic system
• Application: Safe removal of ball
joint pivots and ball joints
• Surface: galvanized (free from Cr 6)
4961 N
-023 M/5 -023 S/5
R

1 è 4
• Hexagon insert for firm hold on the device
• Special grinder for optimal cleaning of the bearing surface of a wheel
rim (wheel hubs) on trucks and transporters with stud bolt
• 8-point profile enables safe and firm fixation of the
grinding wheel to the base component
• Inner x max.: 23 mm
• Grinding wheel x 56 mm, stud bolt maximum length 100 mm
• Made in Germany (base component made of aluminium) C
12-piece set ∙ contents:
1 base component made of aluminium
5 grinding wheels for moderate soiling
6 grinding wheels for heavy soiling
4961 N-23/12 12 186754
1 1 U 4 • Hook and loop fastener for quick changing of grinding wheels
• 5 spare grinding wheels for moderate soiling, outside
• For passenger cars ∙ vans ∙ commercial vehicles x 56 mm, maximum inside x 23 mm
• Load maximum 12 tonnes 4961 N-023 M/5 5 187270
1790-5 32 70 145461 • Hook and loop fastener for quick changing of grinding wheels O
• For commercial vehicles, buses and building machinery • 5 spare grinding wheels for heavy soiling, outside
• Load maximum 12 tonnes x 56 mm, inside x maximum 23 mm
1790-6 40 85 145478 4961 N-023 S/5 5 187287
Cardan shafts

4685-1 Taper key extractor 4685-2 Taper key extractor A

Made in Germany Made in Germany
• Application: Safe removal of taper keys from the sprockets of agricultural • Application: Safe removal of taper keys from the sprockets of agricultural
machinery as well as manual operation of input shafts on accessory equipment machinery as well
as manual operation
of input shafts on
accessory equipment

U

1 K 4 1 K 4
4685-1 420 222889 4685-2 366 222896

Components and spare parts from page 500 to 509 Errors excepted 491
