Specialty tools

Commercial vehicles – Chassis

4937 Commercial vehicle pin wrench set 4937 Commercial vehicle pin wrench set

Made in Germany 9 F C 9 F
• For repair and maintenance work on the wheel hub, wheel
bearing or brake disc rear axle on MAN and MERCEDES-BENZ
• For MAN and MERCEDES-BENZ 10 t and 13 t AP Hypoid and 1 è 4
tag axle N7/4 ∙ Omnibus 0305G ∙ 0405G 4937-101/4 4 199266 G
MAN hub reduction rear axle F series H7 ∙ HD7
Hypoid axle F series HY-1175 ∙ HDY-1175
• Precise fit 4937 Commercial vehicle pin wrench
• Precise pin geometry for ideal tool operation in slotted nuts
• Solid design: High (shape) stability even with high loosening or tightening torques
• Inner x: 103 mm Made in Germany 9 F
• Length (total): 140 mm • For rear axle MERCEDES-BENZ
• 6 pins, width of pins: 11.5 mm • For rear axle nuts MERCEDES-BENZ Actros ∙ Atego
• Two replaceable guide tubes (heavy design): LN2 ∙ SK
Outside-x: 51.5 mm ∙ 66.5 mm rear axle: 740.0/9 – 744.8 F
Length (total): 135 mm 745.7 – 747.7 – 748.2
• Surface: burnished HD 7/19 DG 13 ∙ HD4/16-1
• With outside guide collar
• Precise fit
• Precise pin geometry for ideal tool operation in pin nuts
• Solid design: High (shape) stability even with
high loosening or tightening torques
• Inner x: 62.8 / 70 mm
• 6 pins, width of pins: 7.5 mm
• Surface: burnished D

R

1 è 4
4937-103/3 3 199259
1 K 4
Made in Germany 9 F
• For dismantling / assembly work on the rear axle as well as 4937-62 85 199020 C
repair and maintenance work on the wheel hub, wheel bearing or brake disc
rear axle MERCEDES-BENZ
4937 Commercial vehicle axle nut socket
• MERCEDES-BENZ hub-reduction axle, such as tag axle NR 7/4
• MERCEDES-BENZ hub-reduction rear axle (Euro-axles) 10 t and 13 t, Made in Germany 9 F
HL7/0 ∙ HL7/1 ∙ HL7/2 ∙ HL7/3, • Dismantling / assembly of the front axle nut with 8-point in
HL7/18 ∙ HO7/8 ∙ HO7/9 ∙ HL7/015, front of the brake disc
HL7/021 ∙ HD7/2 ∙ HD7/19DG ∙ HD7/016DG
• MERCEDES-BENZ hub-reduction axle 7 t AL7/1 • SCANIA Series R ∙ Series 4 ∙ Series 124 I - 144 I - etc.
• Precise fit • Suitable for impact wrenches, e.g. HAZET 9013SPC ∙ 9013MG O
• Precise pin geometry for ideal tool operation in slotted nuts • Precise fit
• Solid design: High (shape) stability even with high loosening or tightening torques • Parallel surfaces for perfect force fit on axle nuts
• Inner x: 101.5 mm • Solid design: High (shape) stability even with
• Length (total): 140 mm high loosening or tightening torques
• 12 pins, pin width: 11.4 mm • Ä 80 mm 8-point
• Three replaceable guide • For impact operation
tubes • Surface: burnished
External x: 50 ∙ 51 ∙ 53 mm
Length (total): 85 mm
A
• Surface: burnished

U

1 N 4
B 4937-80 90 199006
