Page 492 - HAZET哈蔡特2024英文样本

Specialty tools Specialty tools

Commercial vehicles – Brakes Commercial vehicles – Chassis

4971 Brake calliper resetting tool 4972 Lifting aid

Made in Germany R Made in Germany FCRC
• Adjusting with nut-driver Ä 12 mm • Allows you to work safely, without straining your back, in
tight spaces in the wheel arch on trucks, buses, trailers and trailer axles
• Application: Operation of the adjuster (adjusting the brake calliper) on Knorr-
G • Special 11-tooth profile • Application: Secure retention and movement of heavy
Bremse disc brakes on trucks, buses, trailers and trailer axles from all brands
components, e.g. when disassembling and assembling brake
callipers and wheel hubs on commercial vehicles
• Makes fitting screws easier
• Takes the various installation situations of the brake callipers into consideration
• Easy to use
• One-hand operation
possible via spindle
• Second person not required
• Setting range min./max.:
716 – 911 mm
F

1 K G H c 4
4971-11 18 15 11.5 9.8 218257

4971 Brake calliper resetting tool
D Made in Germany
• Special insert in the ratchet wrench ensures safe power c R
transmission on the resetting device
• Application: Resetting WABCO brake callipers without removing the
brake cylinder on MERCEDES-BENZ Actros, Antos, Arocs
• Non-slip HAZET 3-component handle – allows high power transmission YouTube Clip

R

4972-1 4972-2

C

1 K 4
4972-1/2 4972-3 4972-4
4971-12 454.4 232857

1 è 4

• Lifting aid
O consisting of lifting aid 4972-3, – brake calliper holder
4972-1 and wheel hub holder 4972-4
• Maximum load: 75 kg
4972-1/3 3 215799
• Brake calliper holder
• Maximum load: 35 kg
4972-1 – 215423
• Swivel bearing
• Use with brake calliper holder 4972-1
A • For disassembly and assembly of brake callipers in trucks,
buses, trailers and trailer axles that are installed in a diagonal
„clockwise position between 8 o‘clock and 5 o‘clock“
• Easy to set the screws, even in awkward positions
• Connect swivel bearing to brake calliper holder and position
with e.g. jacking carriage below brake calliper
4972-2 – 215393
• Lifting aid single,
without brake calliper holder 4972-1 and wheel hub holder 4972-4
• Maximum load: 75 kg
4972-3 – 215782
U • Wheel hub holder
• Use with lifting aid 4972-3 or 4972-1/3
• Assembling and disassembling wheel hubs
• Maximum load: 70 kg
4972-4 – 216031
490 Errors excepted Components and spare parts from page 500 to 509
