Specialty tools

Commercial vehicles – Engine

1788 T Impact extractor 4797 Injector extractor

Made in Germany C ß
• Application: For disassembly of tight common rail
injectors without removing the cylinder head

• Impact extractor (sliding hammer – sliding weight 200 g) with coupler thread M10 G
• Removal of caps with inside thread, ball bearings, washers etc.
• To be used with stud bolt set 1788T-1/6 and internal extractors 1788N-15 to 35
• Also together with injector extractor 4797-5

1 4

4797-5 176137
2168 Ad-Blue filter wrench F
®
1 R 4
1788 T-1 M 10 134304 Made in Germany c7 D
• Operation of the filter housing cap when replacing the
AdBlue filter (urea solution filter) on MERCEDES-BENZ commercial
®
®
4797 Injector extractor vehicles with BlueTec engines, e.g. Actros, Atego, Axor, Econic
• The tightening torque recommended by the vehicle manufacturer
Made in Germany ß (please follow the instructions of the manufacturer) is reached
• Application: For disassembly of tight common rail e.g. with the torque wrench HAZET 6110-1CT
injectors without removing the cylinder head • h 46 mm D

Easy removal of injectors together with impact extractor e.g. HAZET 1788 T-1
• Injector claw with inside thread M10 x 1.5 mm
• MAN Engines D08 ∙ D20 ∙ D26 ∙ D28
• Suited to the very limited space conditions in the cylinder head
• Due to the tool‘s claw, the injector in the upper part
may be gripped without causing damage
R

1 t 4
B 2168-46 59 156252

Diagnostics

4800 Radiator tester for agricultural machinery C
Made in Germany KG
• Application: Checking for leakage in cooling systems and heating circuits
• Classification to vehicle types: www.hazet.de → Service →
The Tool Finder → Radiator adapters 4800
• Plastic box
• 4800-1 Cooling pump to 2.5 bar
• 4800-2 Intermediary piece, flexible hose
• 4800-3 Radiator adapter for AMAZONE Pantera
CLAAS Jaguar ∙ Lexion ∙ Scorpion ∙ Ares ∙ Atles ∙ Ceres O
FENDT
MASSEY FERGUSSON with tank number 180224M92 and 4296015M1
CASE Quadtruc ∙ Magnum
• 4800-4A Radiator adapter for CASE Puma ∙ SBS ∙ LBS ∙ Optum ∙ Maxxum ∙ CVX
NEW HOLLAND TVT ∙ T7, T7 Elite Pack ∙ T6
FENDT Vario model year 2000 → Combine harvester L series
CLAAS Arion ∙ Axion
DEUTZ engines 3.6 PowerPack ∙ BF6M1013FC ∙ TCD2013L6 2V and 4V genset 250kV
• 4800-5A Radiator adapter for FENDT Farmer 300 model year 1988 → ∙
Type 500 ∙ Type 700 ∙ Vario model year 1988 → 2000
• 4800-20 Radiator adapter for CLAAS Xerion ∙ Tucano as well as all new A
CLAAS machines with MERCEDES-BENZ expansion tank

U

1 è 4
4800/6 6 216482

Components and spare parts from page 500 to 509 Errors excepted 485
