Specialty tools

Body and interior equipment – Commercial vehicles

4850 Nozzle adjusting tool 4852 Dashboard protection set ∙ with handle

• The telescopic handle can be used to indicate the nozzle jet QAK • The light blue colour draws attention to soiling on the individual Q
direction to the windscreen protection panels quicker than conventional grey protective panels do
and therefore prevents the interior from being soiled
• Application: Adjusting the nozzles of the windscreen washing systems
• With pocket clip • Application: For protection against damage to the dashboard,
• Magnetic head: 6 mm x interior lining and vehicle headlining when removing windows G
• Adjusting needle (x 0.7 mm) and protection cap • Clean and professional work
• Sturdy plastic
• Contents:
Protection panel, angled, 270 200 mm
Protection panel, angled, 450 300 mm
Protection panel, straight 270 x 200 mm
Protection panel, straight, 450 x 300 mm

F

1 M N 4 1 è 4
4850-1 155 670 022366 4852/4 4 210114 D

Steering wheel

1776 Pitman arm puller ∙ 2-arm 2223 LG Bit

Made in Germany Q Made in Germany NF Q
• For ball bearings, toothed wheels, pinions, • Long design R
pitman arms and similar • Hexagon drive similar to ISO 1173 C6.3 ( ⁄4″)
1
• The clamp clip is used for pressing the puller
jaws on the parts
to be extracted
• Surface: galvanised

1 K r 4
• Round blade C
• For all MERCEDES-BENZ passenger cars
model year → 2011 with bolted air bag unit
1 U a 4 • For removal and installation of the airbag unit e.g. MERCEDES-BENZ ∙
VW ∙ AUDI ∙ OPEL/VAUXHALL ∙ PORSCHE (inside h screws T30)
1776-100 90 100 135950 2223 LG-T 30 70 5.52 015092
Commercial vehicles
Engine O

Cylinder head

2850 3/4″ Impact socket ∙ h

Made in Germany e9 J/
• Operation of cylinder head bolts
A
• Reinforced design
• Long design
• With borehole for locking pin or safety spring and grove for O-ring
• Surface: phosphatized, oiled

1 Ä K G H r c 4

• MAN commercial vehicles F 2000, F 90, F 8 and U
MAN buses with D 25 and D 28 engines
2850-E 20 E20 110 25 44 18.49 15 079681
• MAN commercial vehicles with Common Rail Engine (D20)
2850-E 24 E24 110 30 44 22.16 17.5 146758

Components and spare parts from page 500 to 509 Errors excepted 483
