Specialty tools Specialty tools

Commercial vehicles – Chassis Commercial vehicles – Chassis

4937 Commercial vehicle axle nut socket 4937 Commercial vehicle oil caps

Made in Germany c9 F / axle nut socket
• Nut-driver tuned to the axle nut ensures secure mounting Made in Germany 9 F
of axle nuts • Operation of the oil cap on the front axle
G • Application: Front axle screw connection for DAF CF and XF series • For e.g. IVECO Stralis and Eurofire ∙ MERCEDES-BENZ
• Solid design: high (shape) stability even with high loosening or tightening torques
Discos Trailer with compact bearing hub unit ∙ BPW Eco
• DAF: Plus 1 ∙ BPW Eco Plus 3 ∙ GIGANT trailer axles
CF FA ∙ FT ∙ FAR ∙ FAN ∙ FAT ∙ FTT ∙ FTP ∙ FTG ∙ FAD ∙ FTS ∙ FTR • Precise fit
CF 65 FA • Solid design: High (shape) stability even with high loosening or tightening torques
CF 75 FA ∙ FT ∙ FAR ∙ FAG ∙ FAT ∙ FAD
CF 85 FA ∙ FAR ∙ FAG ∙ FAN ∙ FAT ∙ FAC ∙ FAX ∙ FAQ ∙ FAD ∙ FT ∙ FTP ∙ FTS ∙ • Output: Ä 95 mm
FTR ∙ FTG ∙ FTT • Surface: burnished
XF FA ∙ FT ∙ FAR ∙ FTP ∙ FAN ∙ FTG ∙ FTT ∙ FAD ∙ FAS ∙ FAT ∙ FAK ∙ FTM ∙ FAG ∙
FAR
XF 95 FA ∙ FAD ∙ FAK ∙ FAN ∙ FAR ∙ FAS ∙ FAT ∙ FT ∙ FTG ∙ FTM ∙ FTP ∙ FTR ∙
FTS ∙ FTT
F • Surface: burnished
XF 105 FA ∙ FAR ∙ FAS ∙ FAT ∙ FAK ∙ FAD ∙ FT ∙ FTG ∙ FTS ∙ FTT ∙ FTM

D

1 N 4
1 N 4 4937-95 117 199457

R 4937-S 80 63 206889 4937 Commercial vehicle centring sleeve set
Made in Germany F
• With guide collar Made in Germany 8 F
• Application: Fast assembly of centred
• Application: Operation of the rear axle nut on e.g. IVECO Daily 6.5 t ∙ 7.0 t commercial vehicle drop centre rim wheels
• Nut-driver completely encloses the flat rear axle nut for secure work for rim hole x 26 mm M22 x 1.5
• Suitable for impact wrenches, e.g. HAZET 9013SPC ∙ • For e.g.: DAF ∙ FORD ∙ MAN ∙
9013MG with socket 1000S-36 MERCEDES-BENZ ∙ RENAULT ∙ Volvo
• Precise fit • No damage of the thread as well as exact centring
of the rims through conically cranked bushes
C • Parallel surfaces for perfect force fit on axle nuts • High fitting accuracy through
• Solid design: High (shape) stability even with high loosening or tightening torques
• Hexagon drive Ä 36 mm precise thread production
• Output: Ä 90 mm • Inside thread: M22 x 1.5 mm
• For impact operation • Surface: burnished
• Surface: burnished

1 K è 4
O 4937-26/3 115 3 199013

4937 Commercial vehicle mounting
sleeve MAN ∙ thread M100 x 1.5
Made in Germany F
• Mounting sleeve to protect the thread on the axle during bearing
disassembly and assembly

A • Use with MAN TGX ∙ TGA ∙ TGS
e.g. for MAN HY 1350 axle (13 tonnes) ∙ F2000 ∙ Lion‘s Star ∙
Lion‘s Regio ∙ Lion‘s Coach ∙ Lion‘s Classic ∙ ND ∙ NUE ∙ NM ∙
NEOPLAN Starliner ∙ Cityliner ∙ Centroliner ∙ Trendliner
• Only lift the approx. 40 kg bearing unit (bearing, brake
disc and wheel hub) onto the mounting sleeve once,
then push up to the bearing seat with x 105 mm
• Thread: M100 x 1.5
• Outside x: 105 mm
• Drive via chequered handle surface or suitable lateral rod
• Surface: burnished
U

1 N 4 1 t 4
4937-90 115 199280 4937-100 105 201983
