LEAD FORMING CUSTOM TOOLS

Formers HHHHH ULTRA PRECISION

500 Series Molded Grip - Surface Resistivity - 10 ohms/sq
8
900 Series Cushion Grip - Surface Resistivity - 10 ohms/sq
10

954B 5.75” (155mm) 554-TX-US 5.5” (137mm)
Designed to form a consistent standoff in a variety of Stress relief forming plier will form stress relief in most
components. Similar to the 554A-US, made on a larger radial lead components. Designed to form one
frame these pliers can form leads and wires up to .035” lead in and one lead out in a single operation. It’s
(.88mm) diameter. Featuring cushioned ergonomic grips recommended for .025” (.63mm) dia. or smaller wire.
with dual leaf springs. Featuring molded ergonomic grips with dual leaf springs.

909-4 5” (125mm) 554-TXB-US 5” (125mm)
Stress relief forming plier provides stress relief forming Stress relief forming plier will form stress relief in most
for transistor and resistor leads. Tool design is versatile radial lead components. Designed to form one lead in
in a variety of applications. Recommended for .035” and one lead out in a single operation. Recommended
(.88mm) wire or smaller. Featuring soft cushioned for .025” (.63mm) dia. or smaller leads and wires.
ergonomic grips with dual leaf springs. Featuring a molded ergonomic grip with dual leaf
springs.

909-4B 6.25” (156mm) 554-3RB-US 5.25” (131mm)
Stress relief forming plier may be used for many types Lock-in lead forming plier will form an “s” bend on a
of components. The smaller dimensions keep component lead, enabling the component to stay in
components close to the PC board. Recommended for place when soldering. Recommended for .025” (.63mm)
.030” (.75mm) or smaller leads and wires. Featuring soft dia. or smaller leads and wires. Featuring molded
cushioned ergonomic grips with dual leaf springs. ergonomic grips with dual leaf springs.

54 805.686.4686 | WWW.EXCELTA.COM
