LEAD FORMING CUSTOM TOOLS

Cutters/Formers HHHHH ULTRA PRECISION

500 Series Molded Grip - Surface Resistivity - 10 ohms/sq
8
900 Series Cushion Grip - Surface Resistivity - 10 ohms/sq
10

554-TXC-US 5.5” (137mm) 500-13A-US 5” (125mm)
Will form one lead in and one lead out at the same time .375” (9.38mm) fl at pack forming plier/cutter will form a
on most radial type components. The added shear “Gull Wing” and cut multiple leads to length on various
cutter saves component prep time. Cutting capacity types of fl at packs. Cutting capacity is .010” (.25mm) soft
is .025” (.63mm) dia. soft wire. Featuring a molded wire. Featuring molded ergonomic grips with dual leaf
ergonomic grip with dual leaf springs. springs.

900-10 5.5” (137mm) 500-13B-US 5.5” (137mm)
Will cut and form 3 or 5 leads on a TO-220 style .250” (6.25mm) fl at pack forming plier/cutter will form a
component. Leads will be formed to the bottom of “Gull Wing” and cut multiple leads to length on various
component body for surface mounting. Featuring soft types of QFP and SOIC packages. Cutting capacity is
cushioned ergonomic grips with dual leaf springs. .010” (.25mm) soft wire. Featuring molded ergonomic
grips with dual leaf springs.

500-103-US 5.5” (137mm) 907-89B 5.75” (155mm)
Designed to form TO-220 style transistors with 3 or 5 leads. Dog leg lead forming plier is a heavy duty plier
Component leads are formed .200” (5mm) from the designed to increase or decrease the center dimension
body of the component. Featuring molded ergonomic on radial lead components. Featuring soft cushioned
grips with dual leaf springs. ergonomic grips with dual leaf springs.
