CUSTOM TOOLS LEAD FORMING

HHHHH ULTRA PRECISION INSERTION/EXTRACTION

500 Series Molded Grip - Surface Resistivity - 10 ohms/sq
8

Part# A B C Pins
505-US 5.5” (137mm) 505-US .18" (4.5mm) .4" (10mm) 1.062" (26.55mm) 18-22
Our 505 Series pliers have been designed to handle 505A-US .18" (4.5mm) .6" (15mm) 1.260" (31.5mm) 24
DIP/IC packages. The chart will help you quickly fi nd 505B-US .18" (4.5mm) .6" (15mm) 2.080" (52mm) 40
the size you are looking for. 505BG-US .18" (4.5mm) .6" (15mm) 1.398" (35mm) 28
505C-US .18" (4.5mm) .3" (7.5mm) .7880" (19.7mm) 14-16
505D-US .18" (4.5mm) .3" (7.5mm) .3580" (.95mm) 6-8
505E-US .18" (4.5mm) .3" (7.5mm) 1.260" (31.5mm) 24
505F-US .18" (4.5mm) .3" (7.5mm) .2570" (6.43mm) 4
505G-US .18" (4.5mm) .3" (7.5mm) 1.660" (41.5mm) 32
505J-US .18" (4.5mm) .3" (7.5mm) .9660" (24.15mm) 20
505K-US .18" (4.5mm) .3" (7.5mm) 1.398" (35mm) 28
505H-US .18" (4.5mm) .6" (15mm) 3.30” (82.5mm) 48
505-20-US-ST .18" (4.5mm) .4” (10mm) 1.06” (26.5mm) 18-22
Custom size pliers available upon request.
