LEAD FORMING CUSTOM TOOLS

Formers HHHHH ULTRA PRECISION

500 Series Molded Grip - Surface Resistivity - 10 ohms/sq
8

500-104-US 5” (125mm) 500-210-US 5.5” (137mm)
Transistor forming plier is used in forming 3 leads on a Multiple lead forming plier is designed to bend the leads
TO-220 style transistor. The two outside leads will be on LEDs and other multiple lead components. Leads
bent .200” (5mm), while the center lead is bent .300” are formed to 90° and .100” from the component body
(7.5mm) from the body of the component. Featuring without damage. Recommended for use on .025”
molded ergonomic grips with dual leaf springs. diameter leads and wires. Featuring molded ergonomic
handles with dual leaf springs.

500-95B-US 5.5” (137mm) 500-210A-US 4.75” (119mm)
Dog leg lead forming plier is designed to form a “Dog Adjustable multiple lead forming plier is designed to
Leg” bend in the lead wire. This tool can be used to form transistor leads with .100” (2.5mm) center spacing.
increase or decrease the center dimensions of the radial Leads are formed at 90° for through-hole mounting.
lead components. Recommended for .030” (.75mm) or The distance from the component body to the end
smaller leads and wires. Featuring molded ergonomic is adjustable from .100” (2.5mm) to .300” (7.5mm).
grips with dual leaf springs. Featuring molded ergonomic grips with dual leaf springs.

500-104B-US 5” (125mm)
Transistor forming plier is an elaborate design for forming
5 leads on a TO-220 component in one easy operation.
The tool will ensure uniformity of diffi cult lead alignment.
Featuring molded ergonomic grips with dual leaf springs.
