CUSTOM TOOLS LEAD FORMING

HHHHH ULTRA PRECISION Cutters/Formers

500 Series Molded Grip - Surface Resistivity - 10 ohms/sq
8
900 Series Cushion Grip - Surface Resistivity - 10 ohms/sq
10

500-89B-US 5.5” (137mm) 900-88B 5.75” (144mm)
Dog leg lead forming plier/cutter is designed to increase This stress relief forming plier/cutter is designed to form
or decrease the center dimension on radial lead stress relief and cut leads to a specifi c dimension in one
components. The added shear cutter saves component easy step. Cutting capacity is .020” (.5mm) dia. soft wire.
prep time. Cutting capacity is .025” (.63mm) dia. soft Featuring soft cushioned ergonomic grips with dual leaf
wire. Featuring a molded ergonomic grip and dual leaf springs.
springs.

907-88 6” (150mm) 907-89 5.75” (144mm)
This stress relief forming plier/cutter is designed to form Dog leg lead forming plier/cutter is designed to increase
a standoff and cut leads to length on most popular or decrease the center dimension on radial lead
radial lead components. Cutting capacity is .030” components. The added shear cutter saves component
(.75mm) dia. soft wire. Featuring soft cushioned prep time. Cutting capacity is .030” (.75mm) dia. soft
ergonomic grips with dual leaf springs. wire. Featuring soft cushioned ergonomic grips with dual
leaf springs.

907-88C 6” (150mm)
The smaller design of this tool will “Standoff” the
component closer to the PC board. The added Shear
cutter saves on component prep time. Cutting capacity
is .025” (.63mm) dia. soft wire. Featuring soft cushioned
ergonomic grips with dual leaf springs.
