LEAD FORMING CUSTOM TOOLS

Cutters/Formers HHHHH ULTRA PRECISION

500 Series Molded Grip - Surface Resistivity - 10 ohms/sq
8
900 Series Cushion Grip - Surface Resistivity - 10 ohms/sq
10

500-108-US 5.5” (137mm) 930E-1 5.5” (137mm)
Designed to bend leads to 45° then cut the lead to Designed to cut leads to .060” (1.5mm) then bend the
.050” keeping component in place when soldering. lead keeping the component in place when soldering.
Recommended cutting capacity is .025” (.63mm) dia. Cutting capacity is .032” (.8mm) dia. soft wire. Featuring
soft wire. Featuring a molded ergonomic grip with dual soft cushioned ergonomic grips with dual leaf springs.
leaf springs.

530E-1-US 5” (125mm) 500-88-US 5” (125mm)
Designed to cut leads to .060” (1.5mm) from the PC Designed to form a consistent standoff and cut the lead
board, then bend the lead to 30° keeping components to length on most popular radial lead components.
in place when soldering. Cutting capacity is .025” Cutting capacity is .025” (.63mm) dia. soft wire.
(.63mm) dia. soft wire. Featuring molded ergonomic Featuring a molded ergonomic grip with dual leaf
grips with dual leaf springs. springs.

907 6” (150mm) 500-89-US 5.5” (137mm)
Designed to cut leads to .030” (.75mm) and swages the Dog leg lead forming plier/cutter is designed to increase
end of the lead to prevent it from falling out of the P.C. or decrease the center dimension on radial lead
board. Cutting capacity is .032” (.8mm) dia. soft wire. components. The added shear cutter saves component
Featuring soft cushioned ergonomic grips with dual leaf prep time. Cutting capacity is .025” (.63mm) dia. soft
springs. wire. Featuring a molded ergonomic grip with dual
leaf springs.
