CUSTOM TOOLS LEAD FORMING

HHHHH ULTRA PRECISION Formers

500 Series Molded Grip - Surface Resistivity - 10 ohms/sq
8
900 Series Cushion Grip - Surface Resistivity - 10 ohms/sq
10

500-92-US 5.5” (137mm) 554B-US 5.5” (137mm)
TO-92 lead forming plier has slots on the outside jaw to Stress relief forming plier is designed to form a consistent
help the plier fi t between the leads of a TO-92 and fl are relief of a variety of components. It’s recommended for
them out .050” (1.25mm) forming a “Standoff” in the .020” (.5mm) or smaller wire. Featuring molded
lead wires. Featuring molded ergonomic grips with dual ergonomic grips with dual leaf springs.
leaf springs.

500-11-US 5.5” (137mm) 554F-US 5.5” (137mm)
Off-set lead forming plier is used to form a single lead Stress relief forming plier is our smallest forming plier used
on TO-220 style transistor. The lead can be formed .100” to form a standoff on component leads of .020” (.5mm)
(2.5mm). Featuring a molded ergonomic grip with dual dia. or smaller. Featuring molded ergonomic grips with
leaf springs. dual leaf springs.

554A-US 5” (125mm) 954A 6” (150mm)
Stress relief forming plier is designed to form stress relief Stress relief forming plier is designed to form a consistent
for transistor and resistor leads. The tool design will stress relief on a variety of components. Similar to the
make consistent standoff on a variety of components. 554A-US, made on a larger frame, these pliers can form
Recommended for .025” (.63mm) and smaller wire. leads and wires up to .030” (.75mm) dia. Featuring soft
Featuring molded ergonomic grips with dual leaf springs. cushioned ergonomic grips with dual leaf springs.
