21

T-bracket C-bracket & Lubricators Filters, Regulators,
T-brackets provide an excellent solution for C-brackets are designed to hold either a
wall-mounting your FRL unit. They can be used single ilter or single lubricator unit. The
for single or combination conigurations in the bracket has two holes to allow for the unit
modular arrangement. T-type brackets give good to be bolted to a wall or other lat surface.
wall-to-unit clearance for installing ittings or Mounting hardware not included.
other connections. Kit includes bracket, modular
clamp, and bolt(s). Model Number Size Material Description
104407 1000 Series
Model Number Size Material Description 104408 1500 Series C-type
Steel
104399 1000 Series Nylon 104409* 2000 Series wall bracket
104400 1500 Series Nylon 104410 3000 Series
T-type wall mounts
104401 2000 Series Aluminum *Does not it 3/4" NPT ilter
104402 3000 Series Aluminum

Modular clamp & spacer kit L-bracket
L-brackets are designed to allow the user
Modular clamps are used to connect to mount a regulator or piggyback unit to a
any two modular FRL units or wall or lat surface. A panel nut should be
accessories together. The kit includes used to keep the unit in place. Panel nuts
both a front and a back clamp, along are included as standard equipment on all
with the connecting bolt(s). The steel ARO-Flo regulators and piggybacks, and
bolts are metric hex head. replacements can be ordered separately.

Model Number Size Material Description Model Number Size Material Description
104394 1000 Series Nylon 104403 1000 Series
104395 1500 Series Aluminum Modular / clamp 104404 1500 Series Steel L-type
104396 2000 Series Aluminum & zinc spacer kit 104405 2000 Series wall bracket
104397 3000 Series Aluminum 104406 3000 Series

Panel nut

The panel nut allows the user to attach
the regulator or piggyback unit to a panel
or L-bracket. Panel nuts are included as
standard on all ARO-Flo Series regulators
and piggybacks.

Model Number Size Material Description
104416 1000 Series
104417 1500 Series
Nylon Panel nut
104418 2000 Series
104419 3000 Series

For further model options, port sizes, and
information regarding flow charts, unit dimensions, ingersollrandproducts.com/accessories
replacement parts, and more, go to:
