ToneMaster /Tone Generator and ToneSeeker /Tone Tracer
™
™
The Platinum Tools ToneMaster high-power tone generator enables signal detection over 20 miles away and makes hearing tone through
walls and enclosures easier with multiple tones and power levels suited for network, signal wire, coax, and telephone cable applications. Four
tone amplitude levels include normal and half plus, high-powered normal, and half, with the half amplitude unbalanced for stronger signal
effect on twisted pairs. In addition, depending on test requirements, three distinctly different tone cadences can be selected from the front
panel. Paired with the Platinum Tools ToneSeeker, the ToneMaster makes easy work of tracing and locating cables and cable ends.

Features
ToneMaster High-Powered Tone Generator
• 700% more power than standard tone generators
• Unbalanced tone mode supports longer distances on twisted pair cables
• Constant amplitude output ensures no signal decrease as battery discharges
• Auto-off for battery conservation
• Full talk battery to power a dry line
• Tone may be added in any mode
• Models available with molded-in alligator clips
or molded-in angled bed-of-nails (ABN) clips
• Lanyard attachment point
TG210K1
ToneSeeker Tone Tracer Probe

• Slim ergonomic shape, balanced weight
• Volume thumbwheel Piercing Clip
• Recessed “Push-to-Trace” button Angled Bed-Of-Nails
• Tip replacement without opening case
• Battery-low Indicator
• Lanyard attachment point
Includes Belt Pouch, 9V Batteries,
RJ12 Cable, and User Manual.
Professional Tone and Probe Kits

TG210K1 TG220K1
Kit Includes: Kit Includes:
• ToneMaster w/Alligator Clips • ToneMaster w/ABN Clips
• ToneSeeker • ToneSeeker Made
• No-Fault, RJ12 Cable • Coax Toning Cable • No-Fault, RJ12 Cable • Coax Toning Cable in the USA
• Tone and Probe • RJ45 Coupler • Tone and Probe • RJ45 Coupler
Belt Pouch Belt Pouch
Part # Description Part # Description
TG210K1 Professional Tone and Probe Kit TG220K1 Professional Tone and Probe Kit
w/Alligator Clips, Belt Pouch, Box w/ABN Clips, Belt Pouch, Box
TG210K1C Professional Tone and Probe Kit TG220K1C Professional Tone and Probe Kit
w/Alligator Clips, Clamshell w/ABN Clips, Clamshell

Part # Description
TG210C ToneMaster High-Powered Tone Generator w/Alligator Clips 700% More Power
™
TG220C ToneMaster High-Powered Tone Generator w/ABN Clips Than Standard Tone
™
TP250C ToneSeeker Tone Tracer Probe Generators
™
