Test & Measurement

Cable Prowler Cable Tester
™
Provides full color cable testing and report management for Cat3, Cat5e, Cat6, Cat6A, coax, and telephone cable types. The Cable Prowler
combines the functions of a high-end cable tester and length measurement tester, the capability to identify link status, link capability, and
PoE detection. All of this functionality is combined with internal memory to save, download, and output results in full color.
Technical
• Displays length measurement for each pair in feet or meters using TDR technology Made
• Detects presence of PoE and class of PoE per IEEE 802.3af/at with load test in the USA
for voltage drop
• Detects and reports current link speed and link capabilities for active Ethernet
drops up to 1 Gb/s
• Tests Ethernet cable configuration and verifies connectivity while conducting
tests for opens, shorts, miswires, split pairs, and reverses
• Supports up to 8 Testing and ID Remotes for network and telephone cables
• Supports up to 20 network and coax ID only remotes
• View saved cable tests
• Full color graphical wire-mapping
• Ability to define cable name, save cable tests, and print ALL results
(cable testing and network testing)
• Multilingual (English, French, Spanish, German, Italian)

Applications
• Measure cable length and length to faults using TDR technology
• Network testing of link capability, link status, and link light
• Test PoE to ensure adequate power for powered devices such as VoIP phones
• Conduct single ended and remote cable tests with display of PASS, wire map,
ID, and faults for network and coax cables
• Tone and trace cables
• Locate unlabeled network and coax cables with up to 20 remote identifiers
• Test multiple (up to 8) network and telephone drops with testing and identifier remotes
• Define a cable name for your cable test, save every cable test, and
export to your computer for record keeping and printing

TCB360K1
Kit Includes:
• Cable Prowler Main Unit
• Cable Tester Smart Remotes, #1-8
• ID Only Coax Remotes, #1-8
• ID Only Network Remotes, #1-12
• Micro USB Cable
• Cable Assembly, RJ45 to Alligator Clip
• No-Fault, RJ12 Cable (2)
• RJ45 Port Saver
• F Connector Coupler F81 (2)
• BNC Adapter Kit
• Alkaline AA Batteries
• Durable Plastic Case
Part # Description
TCB360K1 Cable Prowler PRO Test Kit
™
