Test & Measurement

VDV MapMaster 3.0 Cable Tester
™
Combines continuity testing, mapping, generating tones, and length measurement Pass
functions into a single easy-to-use unit for installation, troubleshooting, and
maintenance for telco, network, or coax cable. The backlit display, glow-in-
the-dark keypad and a built-in flashlight helps you to work in the dark. Whether
your jobs are commercial or residential, the versatility and added features of the
VDV MapMaster 3.0 makes it a best value cable verifier for the professional installer!

Features
Open and Short
• Detects open, shorts, miswires, reverses, and split pairs
Made
• Tests to T568A/B wiremap configuration: shorts, opens, in the USA
miswires, reverses, and split pairs
• Single-ended testing for shorts and split pairs
• Measures Length in Feet/Meters
• Identifies cable location on active ports using flashing Port Link Light
• Easy to read, backlit LCD screen with large icons, glow-in-the-dark
keypad and built-in LED flashlight for use in dark areas Port Link Light
• Verifies continuity for multiple cable types (LAN, phone, and video)
• Audible beep for additional feedback
• Identify up to 20 network or coax cable runs at a time
• Measures cable length, distance to opens, and breaks in
See pages 88 and 89
specific wires, pairs, or all wires simultaneously for the VDV MapMaster Accessories
• Master remote stored in main unit
• Voltage detection warning icon
• Continuous loop test mode for trouble shooting Top
• Auto-off and timed backlight in any mode for low power Ports Bottom
consumption and long battery life
• Audible tone generation, 4 selectable cadences

Easy to read, backlit LCD
screen with large icons,
glow-in-the-dark keypad, Part # Description
and built-in LED flashlight T130 VDV MapMaster 3.0
™
for use in dark areas.
Cable Tester

T130K3

Kit Includes:
• VDV MapMaster 3.0 Main Unit • Cable Assembly,
• ToneSeeker Tone Tracer Probe RJ45 to Alligator Clip
• RJ45 Port Saver • BNC Adapter Kit
• Cable Tester Smart Remotes, #2-8 • 9V Battery
• ID Only Network Remotes, #1-20 • Large Shoulder Bag
• No-Fault, RJ12 Cable (2)
• FTP Patch Cable, 5" Cat6, (8)

Part # Description
T130K3 VDV MapMaster 3.0
™
Cable Tester Deluxe PRO Kit
