Precision Electronics Diagonal

Cutters ESD

with bolted joint
> Precision pliers for ultra fine cutting work, e. g. in electronics
and fine mechanics 79 02 120 ESD
> Electrically discharging handles – dissipative
> Very precisely ground and sharp cutting edges with very small
bevels for exact cutting on delicate electronic components;
also available without bevel for flush cutting
> Precision cutting edges additionally induction-hardened, cutting
edge hardness approx. 64 HRC
> Approx. 20 % lighter than conventional electronics pliers
> Bolted joint with carefully manufactured joint surfaces for even,
low-friction movement throughout the entire opening range
> Smooth-running double spring for a gentle and even opening 79 02 125 ESD 79 12 125 ESD
> Ergonomically optimised multi-component handles
> Ball bearing chrome steel, forged, multi stage oil-hardened
> DIN ISO 9654, DIN EN 61 340-5

79 02 120 ESD / 79 22 120 ESD
> Mini-head
79 02 125 ESD / 79 22 125 ESD
> Round head
79 12 125 ESD
> Specially for cutting through hard wire and piano wire 79 22 120 ESD 79 22 125 ESD
79 32 125 ESD / 79 42 125 ESD
> Pointed head
79 42 125 Z ESD
> For an optimised flush cutting result of soft materials
79 52 125 ESD / 79 62 125 ESD
> Pointed head; with lead catcher – no uncontrolled loss of cut wire ends

79 32 125 ESD 79 42 125 Z ESD

ESD pliers (electrostatic discharge)
Electrostatic energy is discharged through
the handles in a gradual and controlled
manner. Which protects components
endangered by electrostatic discharge.
In accordance with applicable standards,
e.g. IEC TR 61 340-5, DIN EN 61 340-5,
SP Method 2472

Cutting capacities Dimensions
EAN Ø Ø Ø B A D
Article No. 4003773- mm Pliers Head Handles Ø mm mm mm mm mm mm mm g
79 02 120 ESD 061595 120 burnished polished with multi-component grips 0.2 – 1.4 1.0 0.6 6.5 9.0 6.5 57
79 02 125 ESD 061519 125 burnished polished with multi-component grips 0.2 – 1.7 1.3 0.7 10.0 11.0 6.5 61
79 12 125 ESD 071389 125 burnished polished with multi-component grips 0.3 – 1.7 1.3 1.0 0.6 10.0 11.0 6.5 61
79 22 120 ESD 061618 120 burnished polished with multi-component grips 0.1 – 1.3 0.8 6.5 9.0 6.5 57
79 22 125 ESD 061533 125 burnished polished with multi-component grips 0.1 – 1.7 1.0 10.0 11.0 6.5 61
79 32 125 ESD 061557 125 burnished polished with multi-component grips 0.2 – 1.5 1.1 0.6 11.0 11.0 6.5 61
79 42 125 ESD 061571 125 burnished polished with multi-component grips 0.1 – 1.5 0.8 11.0 11.0 6.5 58
79 42 125 Z ESD 078456 125 burnished polished with multi-component grips 0.1 – 1.3 11.0 11.0 6.5 58
79 52 125 ESD 065159 125 burnished polished with multi-component grips 0.2 – 1.3 0.9 0.5 11.0 11.0 6.5 58
79 62 125 ESD 065166 125 burnished polished with multi-component grips 0.1 – 1.3 0.8 11.0 11.0 6.5 58

ELECTRONICS PLIERS AND PRECISION TWEEZERS I 267
