Cable Cutters

(ratchet mechanism, 3-stage)

► Sturdy. Easy to use. Stable.
► Innovative ratchet-drive

► For cable up to Ø 60 mm
> Fixed handle with support area for putting down the pliers when
cutting 95 36 320
> Easy handling due to low weight (825 g) and compact construction
(320 mm length) – also usable in confined areas
> Cuts through copper and aluminium cables up to Ø 60 mm in
one-hand and two-hand operation
> Hardened, precision-ground cutting edges cut smoothly and neatly
without crushing
> For cutting copper and aluminium single conductors as well as
multiple stranded cables
> Innovative three-stage ratchet-drive with high leverage for easy
cutting in one-hand and two-hand operation
> Not suitable for steel wire, wire ropes and fine-stranded (highly
flexible) conductors
> High-grade special tool steel, forged, oil-hardened
> DIN EN 60900, IEC 60900

Cutting capacities
EAN
Article No. 4003773- mm Tool Head Handles Ø mm mm² MCM g
95 36 320 075189 320 black atramentized polished insulated with multi-component grips, VDE-tested 60.0 600 1200 830
95 39 320 01 075714 Pivot cutter repair kit for 95 32 320 and 95 36 320
95 39 320 02 075721 Fixed cutter repair kit for 95 32 320 and 95 36 320

Cable Cutters

(ratchet mechanism)

for steel wire armoured cables (SWA cable)
► Cuts through steel wire armoured cables up to
Ø 45 mm / 380 mm² (e.g. 4 x 95 mm²) using one
or two-handed operation
95 36 315 A
► Sturdy. Easy to use. Stable.

> Simple handling due to low weight (800 g) and compact design
(315 mm length) – can also be used in confined areas
> Precision-ground blades and induction-hardened cutting edges
cut smoothly and neatly without crushing
> Innovative high leverage three-stage ratchet-drive
> Support area for putting down the pliers when cutting
> Not suitable for cutting ACSR cable and wire rope!
> Cutter head: special high-grade tool steel, forged, oil-hardened
> IEC 60900, DIN EN 60900

Cutting capacities
EAN
Article No. 4003773- mm Tool Handles Ø mm mm² MCM g
95 36 315 A 078579 315 black lacquered insulated with multi-component grips, VDE-tested 45.0 380 750 800
95 39 315 A01 078586 Pivot cutter repair kit for 95 32 315 A and 95 36 315 A
95 39 315 A02 078593 Fixed cutter repair kit for 95 32 315 A and 95 36 315 A

INSULATED TOOLS I 237
