Four-Mandrel Crimping Pliers


        for turned contacts

        > For crimping turned contacts
        > Four-mandrel crimping for top-quality crimp connections
        > Mandrel gauge to check the basic setting
        > Repetitive, high crimping quality due to ratchet mechanism (unlockable)    97 52 63
        > Optimum transmission of force due to highly effective lever action for
         fatigue-reduced operation
        > High operation comfort due to handy shape
        > Special quality chrome vanadium electric steel, oil-hardened
        97 52 63
        > Fine adjustment of pressure depending on the conductor's diameter
         by means of adjusting wheel; pliers in a plastic case with foam insert
         and standard locator for precise positioning of the contacts
        97 52 63 DG
        > Crimping capacity can be adjusted in increments of 0.01 mm;
         With digital display of the preset crimping capacities and possibility   97 52 63 DG
         of re-calibration via RESET function with electronic wear monitoring;
         Adjustment in mm, inches or comparable selection positions according
         to MIL; Pliers in a plastic case with foam insert and standard locator
         for precise positioning of the contacts
        97 52 65
        > Fine adjustment of pressure depending on the conductor's diameter
         by means of adjusting wheel; locator for positioning the contacts;
         with table for calculating the settings ; pliers in a plastic case with
         foam insert
        97 52 65 A
        > Fine adjustment of pressure depending on the conductor's diameter
         by means of adjusting wheel; with table for calculating the settings;   97 52 65  97 52 65 A
         pliers in a plastic case with foam insert
        97 52 65 DG
        > Crimping capacity can be adjusted in increments of 0.01 mm;
         with digital display of the preset crimping capacities and possibility
         of re-calibration via RESET function with electronic wear monitoring;
         adjustment in mm, inches or comparable selection positions according
         to MIL; with table for calculating the settings; pliers in a plastic case
         with foam insert and standard locator for precise positioning of the
         contacts
        97 52 65 DG A
        > Crimping capacity can be adjusted in increments of 0.01 mm;    97 52 65 DG    97 52 65 DG A
         with digital display of the preset crimping capacities and possibility
         of re-calibration via RESET function with electronic wear monitoring;
         adjustment in mm, inches or comparable selection positions according
         to MIL; with table for calculating the settings; pliers in a plastic case
         with foam insert; without positioning guide





                                                             Multi-functional digital display, adjustment in mm, inch or
                                                             comparable selection positions according to MIL










         Turned contacts are used for particularly demanding plug-type
         connections, e.g. in medical industry and aeronautics. Extremely
         reliable crimping connections can be achieved only with pliers that
         work with absolute precision and maintain the required crimping
         depth in the 1/100 mm range.



          200  I CRIMPING PLIERS AND CRIMP ASSORTMENTS
