WIRE PULLING GRIPS Pliers

1625 Series and Crimpers Strippers, Cutters,

• Designed for use when light, compact grip is desired
and where cable deformation is not a factor
162520-114
• Gripping pressure of the knurled jaw is applied to 1/4" (6.35 mm) cable area
• All 1625 series have a swing latch to help hold cable in the jaw
Cat. No. Cable Type Cable Diameter Hot Latch Spring Locking Handle Jaw Type Weight Wrenches Drivers and
2,000 lb (907 kg) Maximum Safe Load
162520-114 Wire Rope 0.75" to 1.25" (19.05 to 31.75 mm) — — — Aggressive 3.7 lb (1.7 kg)
8,000 lb (3,629 kg) Maximum Safe Load
1625-20 Wire Rope 0.28" to 0.75" (7.11 to 19.05 mm) — — — Aggressive 3.5 lb (1.6 kg)
162520-7/8 Wire Rope 0.38" to 0.88" (9.65 to 22.35 mm) — — — Aggressive 3.4 lb (1.5 kg)
162520-1 Wire Rope 0.50" to 1.00" (12.70 to 25.40 mm) — — — Aggressive 3.4 lb (1.5 kg) and Measurement Conduit Tools
Parallel Jaw Grips
Parallel Jaw Grips

Wide Range Transmission Grips
• Securely pulls ACSR, AAC and bare copper cables Tool Kits
• Innovative hot latch with V-notch centers cable (Cat. No. 16499-20)
• Fine Sawtooth jaw geometry provides greater grip strength
• Spring closes grip on cable to hold the initial position
• Made in the USA
• Large opening in the handle accommodates a wide variety of
hooks on hoists, winches and tackle blocks 16499-20 16499 and Comfort Safety, PPE
• Max Safe Load of 12,000-Pound (5443 kg)
• Patent pending design
Cat. No. Cable Type Cable Diameter Hot Latch Spring Locking Handle Jaw Color Jaw Length Weight
16499 — — 8.1 lb (3.7 kg)
Bare Copper, ACSR, AAC 0.68" to 1.42" (17.3 - 36.1 mm) • Gold 4.85" (37.7 cm)
16499-20 • • 8.3 lb (3.8 kg) Accessories Jobsite

Wide Range Distribution Grips
• 50% lighter with one handed grip action
• Holds a wide range of Bare Copper, Aluminum and ACSR cable
• Large opening in the handle accommodates a wide variety of hooks on hoists, winches and tackle blocks Tool Storage
• Patent pending design 16477
Cat. No. Cable Type Cable Diameter Hot Latch Spring Locking Handle Jaw Color Jaw Length Weight
16477 — • — Gold 3.31" (8.4 cm) 2.9 lb (1.3 kg)
Bare Copper, Aluminum, & ACSR 0.162 to 0.883" (4.11 to 22.42 mm)
16477-20 • • • Gold 3.31" (8.4 cm) 3.2 lb (1.5 kg)
16477-24 EHS 0.162" to 0.883" (4.11 to 22.42 mm) — • — Black 3.31" (8.4 cm) 2.9 lb (1.3 kg) Voice/Data/Video
16477-28 HDPE- coated cable (tree wire) 0.162" to 0.883" (4.11 to 22.42 mm) — • — Silver 3.31" (8.4 cm) 2.9 lb (1.3 kg)

HDPE-Coated Cable
• Securely pulls HDPE-coated cable commonly known as "tree wire"
• Innovative high-traction surface grips the cable without damaging the outer jacket Measurement Test and
• Tough carbide grit technology withstands even the harshest jobsite conditions

1716-60 1716-70

Cat. No. Cable Type Cable Diameter Hot Latch Spring Locking Handle Jaw Type Jaw Length Weight
4,000 lbs. (1,814 kg) Maximum Safe Load and Accessories Power Tools
1716-70 • • — Round 4.5" (11.4 cm) 5.10 lb (2.31 kg)
HDPE-Coated 0.625" to 1.362" (15.9 to 34.6 mm)
1716-71 • • • Round 4.5" (11.4 cm) 5.10 lb (2.31 kg)
12,000 lbs. (5,443 kg) Maximum Safe Load
1716-60 HDPE-Coated 0.70" to 1.30" (17.78 to 33.02 mm) — • — Round 5.125" (13 cm) 8.1 lb (3.7 kg) & Structural Lifting, Pulling,

www.kleintools.com > 800-553-4676 303 and Structural Lifting, Pulling,
See Wire Pulling Grips warnings on page 290
