7. 液压驱动及相关附件
7. Drives and Accessoires

KL-0040-258 A (Code 2707497)
KL-0040-258 A
( 编码 2707497)
17 t
用于液压缸 KL-0040-2500 的固定装置
Retaining Device for Hydraulic Cylinder
KL-0040-2500
固定装置 KL-0040-258 A 与变速箱千斤顶 ( 冲头 Ø 30 mm) 结合，可以使用
GEDORE Automotive 工具进行简单和轻松的工作，这些工具由液压缸 KL-0040-
The KL-0040-258 A retaining device is used in conjunction with a transmission jack
2500 驱动。
(Plunger Ø 30mm) thus allowing for the easy and trouble-free operation of all those
GEDORE Automotive tools that are driven by the KL-0040-2500 Hydraulic Cylinder.
推荐配件：
KL-0040-2881 - 夹紧环 ( 用于固定液压缸 KL-0040-2800)
Recommended Accessory:
KL-0040-2571 - 转接器安装套筒 Ø 25 mm
KL-0040-2881 Clamp Ring
(to extend the use of the device to Hydraulic Cylinder KL-0040-2800)
技术参数 :
KL-0040-2571 Adaptor Sleeve, Ø 25mm
支架直径 Ø： 30 mm
Technical Data: 2.6 kg
重量：
Retaining Ø: 30mm
供货范围： 2.6kg
Weight:
KL-0040-258 A - 液压缸的固定装置 KL-0040-2500
Scope of Delivery: 描述 数量
产品编号
KL-0040-258 A Retaining Device for Hydraulic Cylinder KL-0040-2500 1
不带夹紧环的固定装置
KL-0040-2580 A
KL-0040-2587
液压缸的夹紧环
Part No. Description Qty 1
KL-0040-2580 A Retaining Device without Clamp Ring 1
KL-0040-2587 Clamp Ring for Hydraulic Cylinder 1
KL-0040-2571 (Code 2915103)
KL-0040-2571
( 编码 2915103)
17 t
Adaptor Sleeve, Ø 25mm
转接器安装套筒 Ø 25 mm
This adaptor is needed to use the retaining device KL-0040-258 A or the supporting
在将固定装置 KL-0040-258 A 或支撑装置 KL-0145-120 A, 与带有 Ø 25 mm 底座的
device for control arm KL-0145-120 A in conjunction with a transmission jack having
变速箱千斤顶结合使用时需要用到。
a plunger with Ø of 25mm.

液压缸 28 t+ 配件
Hydraulic Cylinder 28t + Accessoires
KL-0040-2800 (Code 2016893)
KL-0040-2800
( 编码 2016893)
28 t
液压缸 28 t
Hydraulic Cylinder, 28t
由于其作为空心活塞缸的特殊结构以及与各种螺杆的结合，液压缸 (28 t) KL-
Thanks to its special design as a hollow piston cylinder, the KL-0040-2800 Hydraulic
Cylinder (28t) can be used to perform pulling as well as pushing operations, in
0040-2800 适用于拉动和推动。
conjunction with the corresponding spindles available as accessories.
用途：
Range of Applications:
与各种 GEDORE Automotive 工具结合，液压缸可用于拆卸和安装球头、轮毂、轮
In conjunction with various GEDORE Automotive tools, the Hydraulic Cylinder
毂轴承、静音轴承和支承接头。
KL-0040-2800 can be used for the removal and installation of drive shafts, wheel
必备配件：
hubs, wheel bearings, silentblocs and suspension ball joints.
KL-0215-35 M28 - 液压泵
Required Accessories:
KL-0215-35 M28 Hydraulic Pump
技术参数 :
最大允许力：
Technical Data: 285 kN (28 t)
最大行程： 50 mm
285kN (28t)
Maximum admissible force:
最大油量： 216.3 cm³
Maximum stroke:
50mm
最大油压： 700 bar
216.3cm³
Maximum volume of oil:
活塞面积： 40.6 cm²
Maximum oil pressure: 700bar
空心活塞中的螺纹： M24
Piston area: 40.6cm²
压力侧的紧固螺纹： 2¾"-16 UNS
Thread in tubular piston: M24
拉力侧的紧固螺纹： M42x2
Retaining thread (pushing side): 2¾“-16 UNS
气缸外径： 99 mm
Retaining thread (pulling side): M42x2
气缸回缩高度： 235 mm
Cylinder outer diameter: 99mm
活塞伸出气缸高度： 285 mm
Cylinder overall length (piston retracted): 235mm
液压离合器连接螺纹： 3/8" NPT
Cylinder overall length (piston extended): 285mm
重量： 9.6 kg
Hydraulic fluid connection thread: 3/8“ NPT
Weight: 9.6kg
