CAULKING GUNS AND OBSTACLE CHECKING

TOOLS

Model No.: EW-20/ EW-30/ EW-50 Model No.: CEM-1/ CEM-2/ CEM-3
Tube obstacle checking tool Caulking gun for cement filling
For obstacle detecting inside tube Tube body Dia. 61mm
Metal tube thickness: Below 4mm Tube volume: 0.9 liter
Plastic tube thickness: Below 6mm Tube body length: 425mm
Cement ground thickness: Max. 280mm Total length: 650mm
Cable length: 20/30/50M Tool weight: 0.87kg
Cup shape: Straight/ Round/ Straight
Outlet: 95*10mm/ Dia. 15mm/ 85*18mm

GC-M GC-2

Scenario diagram
GC-1

Launcher head

Threader

Microphone
for receiver
CEM-1 CEM-2 CEM-3
95*10mm Dia. 15mm 85*18mm

Model No.: HF-99
Silicone scrapper

Receiver
Transmi er

Model No.: PL-3M
Polyethylene overhead line guard
Voltage proof range: AC 20kV/3min.
Tube inner Dia. 35mm Model No.: CS-5
Tube length: 3M Spanners for switch-cabinets
Square size: 5/6/7/8mm
Triangle size: 7-8mm
Circle size: Slotted 2.2mm
I-dia.: 5.5mm
O-dia.: 9mm
Adaptor 1/4”
Screwdriver Bit 1x7mm SL, PH2
