FISH TAPES

BW03 SERIES BW04 SERIES
Safety load: 260kgs Safety load: 300kgs
Breaking strength: 300kgs Breaking strength: 400kgs
Tape Dia.: 4mm Tape Dia.: 4.5mm
Box size: 305mm Box size: 305mm(15/30 ) & 405mm(45/60)
Model No. Length(M) Weight(kg) IN/OUT (CTN)
Model No. Length(M) Weight(kg) IN/OUT (CTN) BW0415 15 1.2 5
BW0315 15 1.2 5 BW0430 30 1.5 5
BW0330 30 1.5 5 BW0445 45 1.8 5
BW0345 45 1.8 5 BW0460 60 2 5
BW0360 60 2 5

BW05 SERIES
Safety load: 400kgs
Breaking strength: 450kgs BW04
Tape Dia.: 5.2mm
Box size: 305mm(15/30 ) & 405mm(45/60)
Model No. Length(M) Weight(kg) IN/OUT (CTN)
BW0515 15 1.3 5 AS & BS SERIES
BW0530 30 1.7 5 Tape material: Spring steel
BW0545 45 2.1 5 Tape Dia.: 3.2*1.6mm
BW0560 60 2.5 5 Box size: 205mm(AS) & 305mm(BS) & 405mm(BS-73B)
Model No. Length(M) Weight(kg) IN/OUT (CTN)
AS-15 15 0.9 10
BS-15 15 1.1 5
BW05 BS-18 18 1.3 5
BS-30 30 1.9 5
BS-45 45 2.4 5
BS-60 60 3 5
AF & BF SERIES BS-73 73 3.4 5
Tape material: Fiberglass BS-73B 73 3.8 5
Safety load: 280kgs
Breaking strength: 330kgs
Tape Dia.: 3.7*2.8mm
Box size: 205mm(AF) & 305mm(BF) AS-15
Model No. Length(M) Weight(kg) IN/OUT (CTN) BS-30
AF-15 15 0.52 10
BF-15 15 1.02 5
BF-30 30 1.26 5
BF-45 45 1.46 5 FISH TAPE WITH NEW SMALL
BF-60 60 1.6 5 20TS STORAGE CARRY
BF-80 80 1.8 5 SHOULDER TUBE
BEST QUALITY THAN JAPAN!

BF-30
AF-15
W0330TS
W0430TS W03420TS
(30M) (20M)
