Precision Circlip Pliers

for external circlips on shafts

► Heavy duty in continuous operation: up to 10 times
longer service life compared to turned tips
► With inserted tips for reliable work

> Large contact faces on the tips: no distortion of circlips, easy fitting
> Bolted joint: precise, zero backlash operation of pliers 49 31 A0
> Internal opening spring, protected and captive
> Slim head style allows use in confined areas
> Inserted tips: spring steel wire, drawn
> Pliers body: chrome vanadium electric steel, forged, oil-hardened
> With overexpansion guard (adjustable using end stop)
> Adjustment using hexagonal screw
> Ideal for series production, as overexpansion of the rings is effectively
avoided
Style 3
> DIN 5254 A; straight jaws
Style 4
> DIN 5254 B; 90° angled jaws 49 41 A01

KNIPEX Circlip Pliers with overexpansion guard
For the suitable fitting of circlips in the industrial serial production. Particularly
manufacturers of sensitive, safety-relevant components (e.g. brakes or gears)
highly appreciate the compliance of DIN 471 and 472. The mounting of circlip
rings in this case requires pliers with overexpansion guard or a cone.
KNIPEX Circlip Pliers with overexpansion guard meet the requirements and
furthermore offer a superior durability.

EAN Size of shaft Tips
Article No. 4003773- mm Style Pliers Handles Ø mm Ø mm g
49 31 A0 061748 140 3 – 10 0.9 103
49 31 A1 073895 140 3 grey atramentized with non-slip plastic coating 10 – 25 1.3 100
49 31 A2 073901 180 19 – 60 1.8 170
49 31 A3 073918 225 40 – 100 2.3 270
49 41 A01 061755 130 3 – 10 0.9 102
49 41 A11 079606 130 90° 4 grey atramentized with non-slip plastic coating 10 – 25 1.3 102
49 41 A21 079613 165 19 – 60 1.8 169
49 41 A31 079620 210 40 – 100 2.3 272

CIRCLIP PLIERS I 075
