Precision Circlip Pliers

for internal circlips in bore holes

► Heavy duty in continuous operation: up to 10 times
longer service life compared to turned tips
► With inserted tips for reliable work

> Large contact faces on the tips: no distortion of circlips, easy fitting 48 11 J2
> Bolted joint: precise, zero backlash operation of pliers
> Non-slip plastic coating on the handles
> Inserted tips: spring steel wire, drawn
> Pliers body: chrome vanadium electric steel, forged, oil-hardened

Style 1
> DIN 5256 C, straight jaws
Style 2
> DIN 5256 D; 90° angled jaws 48 21 J21

High precision quality
Easy and reliable assembly: form-fitting inserted and pressed-in tips
made of high-density spring steel offer a high level of protection
against excessive stress and strain, e.g. when removing stuck rings.
The large supporting surfaces and the position of the tips make it more
difficult for the rings to bounce off.

Sturdy, inserted tips: made from high-density Tight fit through compression
spring steel

Precision and durability
A highly compacted spring steel with a ridge-free surface is used for the tips.
This means that the tip can withstand higher dynamic and static load-bearing
capacity. The tips are 30 % more stable with a single overload compared to
conventional pliers, while at the same time offering good accessibility during
assembly. Under dynamic load, the tip lasts up to 10 times longer!
The tips of the Precision Circlip Pliers are secured by cold forming.
The tips are non-detachable!

EAN Size of bore Tips
Article No. 4003773- mm Style Pliers Handles Ø mm Ø mm g
48 11 J0 048510 140 8 – 13 0.9 105
48 11 J1 048527 140 12 – 25 1.3 105
48 11 J2 048534 180 1 grey atramentized with non-slip plastic coating 19 – 60 1.8 175
48 11 J3 048541 225 40 – 100 2.3 266
48 11 J4 048558 320 85 – 140 3.2 580
48 21 J01 048619 130 8 – 13 0.9 105
48 21 J11 048633 130 12 – 25 1.3 105
48 21 J21 048640 165 90° 2 grey atramentized with non-slip plastic coating 19 – 60 1.8 175
48 21 J31 048657 210 40 – 100 2.3 265
48 21 J41 048664 305 85 – 140 3.2 576

072 I CIRCLIP PLIERS
