Kapitel06_EN.fm Seite 149 Donnerstag, 6. Mai 2021 11:12 11

KL-4306-8320 (Code 1829904) KL-4306-8320
( 编码 1829904)
T 型星形螺丝刀，(T20 x 260 mm)
5-Point Screwdriver with T-Handle
(T20x260mm)
适合 Mercedes。
由于其细长形状，该星型螺丝刀 KL-4306-8320 尤其适用于拆卸和安装 Mercedes 汽车
Suitable for Mercedes.
的外后视镜。
The length and narrow shape of the KL-4306-8320 five-point star screwdriver makes
it ideal for removing and installing exterior rear view mirrors on Mercedes vehicles.
技术参数 :
Technical Data: T20
尺寸：
刀刃长度： 220 mm
100g
Weight:
总长度： 260 mm
T20
Size:
重量： 100 g
220mm
Shaft Length:
Overall length: 260mm
提示：
Note:
对于带有外后视镜的 Mercedes 汽车，安装了以下
On Mercedes vehicles with the outside mirror shown here, the following retaining screws are used:
OEM = Torx® T20 (KL-4306-6320) or 5-point star T20
紧固螺钉：
MB spare part = 5-point star T20
基本装备 = Torx® T20 (KL-4306-6320) 或 5 星 T20
MB 备件 = 5 星 T20
® = reg. trademark of Acument Intellectual Properties, LLC. USA
® = Acument 知识产权有限公司的注册商标。美国
KL-4043-100 (Code 3292002) 11 件式 KL-4043-100
( 编码 3292002)
11 pcs.
1/4”+3/8”批头组套 TorxPlus®
Socket Spanner Set 1/4" + 3/8", IP TorxPlus®
普遍适用于带有 TorxPlus® 螺钉的车辆，例如 VW、Audi、Seat、Skoda、
Universally suitable for cars with TorxPlus® fittings such as VW, Audi, Seat,
Škoda, Renault, Nissan, Opel, Fiat, Toyota, GM, Ford, and many others.
Renault、Nissan、Opel、Fiat、Toyota、GM、Ford 等等。
For loosening and tightening TorxPlus® screwed connections with inner profile such
用于松开和拧紧带有内型材的 TorxPlus® 螺钉，例如在齿带和正时链外壳盖上以及发
as on timing belt or timing chain housing covers as well as on engines and gearboxes
动机和变速箱行。
in general.
Recommended Accessories:
推荐配件：
GEDORE 2093 U-20 Reversible Socket Spanner 1/4",
GEDORE 2093 U-20 - 中空式棘轮两用扳手 1/4"，GEDORE 3093 U-20 - 中空式棘轮
GEDORE 3093 U-20 Reversible Socket Spanner 3/8"
两用扳手 3/8"
Technical Data:
技术参数 :
IP 10; 15; 20; 25; 30; 40; 45; 50; 55; 60
Spanner size:
扳手开口度： IP 10; 15; 20; 25; 30; 40; 45; 50; 55; 60
1/4" + 3/8"
Drive:
驱动方： 1/4" + 3/8"
KL-4043-200 (Code 3292118) 7 件式 KL-4043-200
( 编码 3292118)
7 pcs.
3/8”E 形花套筒，EP TorxPlus®
Socket Spanner Set 3/8", EP TorxPlus®
普遍适用于带有 TorxPlus® 螺钉的车辆，例如 VW 、Audi 、Seat、Skoda 、
Universally suitable for cars with TorxPlus® fittings such as VW, Audi, Seat,
Škoda, Renault, Nissan, Opel, Fiat, Toyota, GM, Ford, and many others.
Renault 、Nissan 、Opel 、Fiat 、Toyota、GM、Ford 等等。
For loosening and tightening TorxPlus® screwed connections with external profile
用于松开和拧紧带有外型材的 TorxPlus® 螺钉，例如在齿带和正时链外壳盖上以及发
such as on timing belt or timing chain housing covers as well as on engines and
动机和变速箱行。
gearboxes in general.
推荐配件：
Recommended Accessories:
GEDORE 3093 U-20 - 中空式棘轮两用扳手 3/8"
GEDORE 3093 U-20 Reversible Socket Spanner 3/8"
技术参数 :
Technical Data:
扳手开口度： EP 10; 12; 14; 16; 18; 20
Spanner size:
EP 10; 12; 14; 16; 18; 20
驱动方： 3/8"
Drive: 3/8"
KL-4043-300 (Code 3292207) 7 件式 KL-4043-300
( 编码 3292207)
7 pcs.
1/2”E 形花套筒，EP TorxPlus®
Socket Spanner Set 1/2", EP TorxPlus®
Universally suitable for cars with TorxPlus® fittings such as VW, Audi, Seat,
普遍适用于带有 TorxPlus® 螺钉的车辆，例如 VW、Audi、Seat、Skoda、
Škoda, Renault, Nissan, Opel, Fiat, Toyota, GM, Ford, and many others.
Renault、Nissan、Opel、Fiat、Toyota、GM、Ford 等等。
For loosening and tightening TorxPlus® screwed connections with external profile
用于松开和拧紧带有外型材的 TorxPlus® 螺钉，例如在车轴部件、飞轮以及通常在发
such as axle parts, flywheels, as well as on engines and gearboxes in general.
动机和变速箱上。
Recommended Accessories:
推荐配件：
GEDORE 1993 U-20 Reversible Socket Spanner 1/2"
GEDORE 1993 U-20 - 中空式棘轮两用扳手 1/2"
Technical Data:
Spanner size:
技术参数 : EP 22; 24; 26; 28; 30; 32
1/2"
Drive:
扳手开口度： EP 22; 24; 26; 28; 30; 32
驱动方： 1/2"
CCopyright GEDORE Automotive GmbH, Germany, 10.E1 formerly 149
