Torque technology                                                                                              Torque technology

                                                       SYSTEM 6000 CT                                                                                                 SYSTEM 6000 CT


        6000-1 CT Torque wrench ∙ SYSTEM 6000CT ∙ ± 2% accuracy ∙ 5 – 800 Nm

           Made in Germany                                                                   234 C/
            •  Accuracy ± 2 % of the scale value (in direction of actuation for right-hand tightening)
         For left-hand tightening, use our torque wrenches with insert tool
        •  HiPer fine-tooth reversible ratchet in 6121-1CT ∙ 6122-1CT ∙ 6123-1CT (90 teeth ∙ 4° operating angle)
        •  High-precision premium torque tools – for the highest demands
        •  Hard chrome-plated steel tube – slim, but very sturdy and wear-resistant
        •  Secure storage in safe box with display window
        •  Safety:
            – Haptic (close-gap release)
            – Audible („click“ sound)
        •  User-friendly reversible ratchet
         Service-friendly (do-it-yourself repair sets for ratchets available)
        •  Integrated shift lever
        •  Easy and safe adjustment of the desired torque value by turning the handle
        •  Knob for additionally locking the set value
        •  Ergonomically shaped handle with collar reduces the risk of slipping-off and injury
        •  Accuracy – fine scale graduation
        •  With calibration certificate and serial number
        •  Surface: hard chrome plated
        •  DIN EN ISO 6789-2:2017, DIN 3120, ISO 1174-1






                                                                                                     YouTube Clip


























        1               Output     K       1       5    Release accuracy   !   Å   Nm     #          4
                                                         tolerance %
                           3
        6110-1 CT     i 10 =  ⁄8″  335     14.5    32       2         5 – 60     0.5      1.9 – 24.7  025022
        6111-1 CT     i 10 =  ⁄8″  389     14.5    32       2        20 – 120    1        6.7 – 42.4  025077
                           3
                            1
        6121-1 CT     i 12.5 =  ⁄2″  437   19.6    44       2        20 – 120    1        6.0 – 37.4  025220
                            1
        6122-1 CT     i 12.5 =  ⁄2″  547   19.6    44       2        40 – 200    1        9.0 – 47.5  025268
                            1
        6123-1 CT     i 12.5 =  ⁄2″  661   19.6    44       2        60 – 320    2        10.8 – 59.6  025367
        •  2-component handle for improved feel
        •  Simplified locking for adjusting the torque value
        •  Viewing window for visual checking of the locking
        •  4 coloured coding rings (red, yellow, green, black) for markings in the case of personalisation or special workflows
        6143-1 CT     i 20 =  ⁄4″  802     28.5    64       2        100 – 400   2.5      14.5 – 59.2  025466
                           3
                           3
        6144-1 CT     i 20 =  ⁄4″  1046    28.5    64       2        200 – 500   2.5      21.6 – 54.6  025541
        6145-1 CT     i 20 =  ⁄4″  1283    28.5    64       2        300 – 800   2.5      25.9 – 70.2  025565
                           3
        •  Torque wrench with DAkkS calibration certificate
                           3
        6110-1 CT CAL  i 10 =  ⁄8″  335    14.5    32       2         5 – 60     0.5      1.9 – 24.7  192915
        6111-1 CT CAL  i 10 =  ⁄8″  389    14.5    32       2        20 – 120    1        6.7 – 42.4  193011
                           3
                            1
        6121-1 CT CAL  i 12.5 =  ⁄2″  435  19.6    44       2        20 – 120    1        6.0 – 37.4  193028
                            1
        6122-1 CT CAL  i 12.5 =  ⁄2″  543  19.6    44       2        40 – 200    1        9.0 – 47.5  193233
                            1
        6123-1 CT CAL  i 12.5 =  ⁄2″  659  19.6    44       2        60 – 320    2        10.8 – 59.6  193240
        •  Torque wrench with DAkkS calibration certificate
        •  2-component handle for improved feel
        •  Simplified locking for adjusting the torque value
        •  Viewing window for visual checking of the locking
        •  4 coloured coding rings (red, yellow, green, black) for markings in the case of personalisation or special workflows
        6143-1 CT CAL  i 20 =  ⁄4″  802    28.5    64       2        100 – 400   2.5      14.5 – 59.2  192922
                           3
        6144-1 CT CAL  i 20 =  ⁄4″  1046   28.5    64       2        200 – 500   2.5      21.6 – 54.6  193035
                           3
        6145-1 CT CAL  i 20 =  ⁄4″  1283   28.5    64       2        300 – 800   2.5      25.9 – 70.2  193042
                           3
        312     Errors excepted                                              Components and spare parts from page 500 to 509
